High Current Toroidal Core Inductor Toroidal Power Inductor 800uH Inductance Range

Categories High Current Power Inductors
Brand Name: Shinhom
Model Number: TR5822
Certification: RoHS
Place of Origin: China
MOQ: 5000PCS
Price: Negotiation
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Delivery Time: 4~8 Weeks
Packaging Details: Carton
est Frequency: 1KHz,0.25V
Inductance range: 800uH
Current range: up to 10A
Footprint: 65mm*45mm
Operating Temperature: -40℃ - +105℃
Inductor Value: Fixed Inductor
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

High Current Toroidal Core Inductor Toroidal Power Inductor 800uH Inductance Range

High current toroidal core inductor,toroidal power inductor,Current up to 10A,800uH


FEATURES:
Lowest DCR/μH
Height:65mm Max
Footprint: 65mm*45mm
Current Rating:up to 10Apk
Inductance Range: 800µH



NOTES:.

  • Test Frequency : 1.0KHz / 0.25Vdc
  • Testing Instrument : L:HP4284A, CH11025,CH3302, CH1320, CH1320S LCR METER/Rdc:CH16502, Agilent33420A MICRO OHMMETER.
  • Heat Rated Current (Irms) will cause the coil temperature rise approximately,△T=40℃ without core loss.
  • Saturation Current (Isat) will cause L0 to drop approximately 25%
  • The part temperature (ambient + temp rise) should not exceed 125℃ under worst case operating conditions. Circuit design, component, PCB trace size and thickness, airflow and other cooling provisions all affect the part temperature. Part temperature should be verified in the end application.
  • Operating Temperature: -40℃ - +105℃.
  • Storage Temperature: -40℃ - +105℃.

Note: Product specifications can be customized.
