L360NB Welding Neck Flanges 1.0582 WN Flanges EN1092-1 Steel Forged Flanges

L360NB welding Neck flanges ( 1.0582 ) wn flanges EN1092-1 Steel forged flanges


Grade :L360NB
Number:1.0582
Classification:Non-alloy quality steel
Density:7.85 g/cm ³
Standard:
EN 10253-2: 2007 Butt-welding pipe fittings. Non alloy and ferritic alloy steels with specific inspection requirements
EN 10208-2: 2009 Steel pipes for pipelines for combustible fluids. Pipes of requirement class B. Technical delivery conditions.

Chemical composition % of steel L360NB (1.0582): EN 10253-2-2007
CSiMnNiPSCrMoVNNbTiAlCu-
max 0.2max 0.45max 1.6max 0.3max 0.025max 0.02max 0.3max 0.1max 0.15max 0.012max 0.05max 0.040.015 - 0.06max 0.25V+Nb+Ti < 0.15, CEV < 0.45


Mechanical properties of steel L360NB (1.0582)
Rm - Tensile strength (MPa)460
Rt0.5 - Yield strength for 0.5% total elongation(MPa)360-510
KV - Impact energy (J) transverse,
40
KV - Impact energy (J) longitud.,
60
A - Min. elongation at fracture (%)20-22


Equivalent grades of steel L360NB (1.0582)
EU
EN
USA
-
Germany
DIN,WNr
L360NB
X52
StE360.7
