U type Sic Rod Heating Elements High Temperature For Industrial
Furnace
Product Description
Silicon carbide heating element is a kind of non-metal high
temperature electric heating element. It is made of selected high
quality green silicon carbide as main material, which is made into
blank, siliconization under high temperature and recrystallized. It
is the most popular type of economical heating element capable of
operating under hot and rigorous environments.
Product Advantages
1. Withstands as high as 1500°C (surface temperature).
2. Various shapes, like Rod shape, U shape, W shape, Single Spiral
& Double Spiral shape, are available to meet your demand.
3. Large size range.
4. Generates high heat output per unit surface area.
5. High strength and excellent shock resistance.
6. Heat source is free of noise and air pollution.
Specification for SIC heater| Diameter | Length of hot zone | Length of cold zone | Overall length | Range of resistance |
| 8mm | 100-300mm | 60-200mm | 240-700mm | 2.1-8.6 ohms |
| 12mm | 100-400mm | 100-350mm | 300-1100mm | 0.8-5.8 ohms |
| 14mm | 100-500mm | 150-350mm | 400-1200 | 0.7-5.6 ohms |
| 16mm | 200-600mm | 200-350mm | 600-1300 | 0.7-4.4 ohms |
| 18mm | 200-800mm | 200-400mm | 600-1600 | 0.7-5.8 ohms |
| 20mm | 200-800mm | 250-600mm | 700-2000mm | 0.6-6.0 ohms |
| 25mm | 200-1200mm | 250-700mm | 700-2600mm | 0.4-5.0 ohms |
| 30mm | 300-2000mm | 250-800mm | 800-3600mm | 0.4-4.0 ohms |
| 35mm | 400-2000mm | 250-800mm | 900-3600mm | 0.5-3.6 ohms |
| 40mm | 500-2700mm | 250-800mm | 1000-4300mm | 0.5-3.4 ohms |
| 45mm | 500-3000mm | 250-750mm | 1000-4500mm | 0.3-3.0 ohms |
| 50mm | 600-2500mm | 300-750mm | 1200-4000mm | 0.3-2.5 ohms |
| 54mm | 600-2500mm | 300-750mm | 1200-4000mm | 0.3-3.0 ohms |
Used in various high temperature electric furnaces and other
electric heating devices, such as in the industries of magnet,
ceramics, metallurgy, glass, and machinery.
Detailed Features of SIC heater:
1. U Type SIC heater
SIC heaters are constructed to from a U-shape. Consequently Type U
have the terminals at one end for a single-phase power source. This
reduces the number terminations and cold ends thus enabling energy
savings.
2.W Type SIC heater
SIC heater with the terminals at one end, is designed for
three-phase power source applications, such as the float glass
process.
3.Spiral Type SIC heater
SIC heater with a spiral-grooved heating section, are more
resistant to heat and corrosion than conventional products and are
able to withstand operation in rigorous conditions. Single spiral
elements are provided with energy-saving, low-resistance, cold-end
terminals.
4.Double Spiral Type SIC heater
SIC heater with a spiral-grooved heating section, are more
resistant to heat and corrosion than conventional products and are
able to withstand operation in rigorous conditions. Double spiral
elements are provided with energy-saving, low-resistance, cold-end
terminals.
5.GC ( Dumb bell type )and GD (Rod)Type SIC heater
GC and GD type SIC heater is made from high-density,high-purity
silicon carbide ,which is the most popular type of economical
heating element capable of operating under hot and rigorous
environments.Notice for using and installing SIC heater
1. Be protected against damp during storing or installing to ensure
the performance ;
2. Divided before assembling. The tolerance of the resistance of
each one cannot exceed by 10% each other;
3. Be careful when using and maintaining;
4. When operating the electric furnace at the beginning, the
voltage should be increased slowly and cannot be fully loaded at
once. Otherwise the larger current will be resulted in the damage
of heater.
5. When heater is damaged and need to be changed, the resistance of
new ne should follow the increasing resistance. If many are damaged
or resistance increased too much, heater should be changed.
