| Categories | Area Velocity Flow Meter |
|---|---|
| Brand Name: | LANRY |
| Model Number: | DOF6000-P |
| Certification: | CE |
| Place of Origin: | Shanghai, China (Mainland) |
| MOQ: | 1 Unit |
| Price: | Negotiable |
| Supply Ability: | 100pcs /week |
| Packaging Details: | carton package |
| Product Name: | DOF6000-P Doppler Ultrasonicl Flowmeter |
| Operating temperature: | -20℃ to +60℃ |
| Power supply: | 85~265VAC, 50 hours Battery, lithium battery |
| Outputs: | 4-20mA, data logger, GPRS (optional) RS485(Modbus), |
| Accuracy: | 1% of reading from 1.5 to 4.5m/s |
| Degree of protection: | IP65 (EN60529) |
The flow meter also can be available with 4-20mA, RS232, RS485 (Modbus) /GPRS and SD card
logger outputs.
1. Measure flow in partially filled pipes and open channels.
2. Rechargeable battery can work up to 40 hours
3. No flume or weir required.
4. Display the velocity, level, flow rate and flow totalizer.
5. 20 coordinate points to describe the river’s shape of cross section.
6. 4-20mA, RS485 (Modbus) /GPRS outputs are available.
| Enclosure type | Portable |
| Power Supply: | 85~265VAC |
| Battery | Lithium battery, 12VDC, 12Ah, Over 40 hours working time on a full-charge |
| Degree of protection | IP65 |
| Operating temperature | -20℃ to +60℃ |
| Enclosure Material | ABS |
| Outputs: | 4-20mA, RS485(Modbus), data logger, GPRS (optional) |
| Application range | Channel: 200-6000mm |
| Weight | 3kg |
| Data logger | 16GB |
| Size | 270L×215W×175H (mm) |
Specifications :DOF6526 sensor
DOF6526 sensor:
Velocity | Range: | 21mm/s to 4500mm/s bi-directional |
Accuracy: | 2% of measured velocity | |
Resolution: | 1mm/s | |
Depth | Range: | 0m to 3.0m or 0m to 6.0m |
Accuracy: | ±0.25% of calibrated lower range | |
Resolution | H2 0-1m at 1mm, 1-2m at 2mm | |
Temperature | Temperature: | -17°C to 60°C |
Resolution: | 0.1°C | |
Flow | Computation: | Flow rate, flow totalizer |
Channel type: | Pipe, open channel, natural stream | |
General | Cable: | 15M |
Cable Options: | User specified up to 100 meters | |
Material: | PVC body, stainless steel mounting plate | |
Dimensions: | 290mm x 70mm x 30mm (L x W x H) | |
Weight: | 1kg (2kg with 15m cable) |
Company
200-6000mm Channel Application DOF6000-P Doppler Ultrasonicl
Flowmeter of Portable Type
With years of export experience along with excellent quality,
advanced services and competitive
prices, Lanry has won numerous customers' trust and support.With years of export experience
along with excellent quality, advanced services and competitive prices, Lanry has won
numerous customers' trust and support.
200-6000mm Channel Application DOF6000-P Doppler Ultrasonicl
Flowmeter of Portable Type
Standard meter: 3-7 days
Special meter: pls feel free to contact us
Express, by air, by sea can be optional.
|
