PC Computer LCD Screen Operation Special Dispensing Controller 4 Axis Glue Dispensing Machine

Categories	Glue Dispensing Machine
Brand Name:	HSTECH
Model Number:	HS-D441
Certification:	CE
Place of Origin:	China
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100 sets per month
Delivery Time:	7~9 work days
Packaging Details:	Wooden package
Product Name:	4 Axis Glue Dispensing Machine
Warranty:	1 Year
Control:	Touch screen
Relay Brand:	Schneider
Optoelectronic Switch:	OMRON
Material:	Aluminum Alloy
Condition:	New
Signal:	SMEMA
Application:	Electronic Assembly
Color:	Silver
Control System:	PLC
OEM/ODM:	Available
Power Consumption:	200W
Type:	Automatic

Contact Now

Add to Cart

Company Info.

Shenzhen Hansome Technology Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

PC Computer LCD Screen Operation Special Dispensing Controller 4 Axis Glue Dispensing Machine

PC Computer LCD Screen Operation Special Dispensing Controller 4 Axis Glue Dispensing Machine

Machine feature

1. PC computer LCD screen operation, easy to program, easy to learn and understand;

2. It has the functions of drawing points, lines, faces, arcs, circles, and continually tween of irregular curves to realize any 3D non-planar track path;

3. The size of the glue, the speed of the glue, the time of dispensing, and the time of stopping the glu e can all be parameterized;

4. With the special dispensing controller, the glue output is stable, the glue is clean and the glue is not leaked;

5. Quickly dot, draw lines and draw circles in the inner, outer wall, vertical surface, gap and spherical surface of the product;

6. According to the needs of customers, it can be equipped with fixtures, glue guns, controllers, heatingtemperature control devices, etc.

7. Optional 1-4 head dispensing device, multiple glue guns at the same time to double the work efficiency;

8. The software has functions such as regional display, translation rotation operation, etc.

9. Adopt trapezoidal acceleration and deceleration, speed preview, micro line interpolation and other technologies;

10. Configure high-speed, low-noise Japanese stepping motor with precise positioning, quick response,stable performance and long service life.

Specification

Model	HS-D441
Power supply	110V/220V 50-60Hz 350W
Glue Mixing Ratio	1:1-10:1/Customizable
Dispensing Speed	10-150g/5s(based on 1:1 glue proportion)
Dispensing Precision	Glue Amount±1%, Glue Proportion±1%
X/Y/Z Working Range	400400100mm(Z axis can be rotated)
XYZ Speed	Max 300mm/s
Drive System	Stepping Motor + Timing Belt
Repeatability	±0.02mm
Pattern	Lines, Circles, Arcs, Continuous Paths, 3D Linear Interpolation
Potting Precision	Amount±1%, Ratio:±1%
Programming	Teach Pendant
Control	PLC
Leak-proof Function	Valve with Vacuum Device
Document Support	CAD, CorelDRAW
Weight	40kg
Dimension(LWH)	616685645mm
