Categories | Rolled Ball Screw |
---|---|
Brand Name: | SXEGL |
Model Number: | SFDC |
Certification: | CE/FCC/EPA/ROSH/ISO |
Place of Origin: | China |
MOQ: | 1 |
Packaging Details: | Carton |
Delivery Time: | Small orders usually takes 3-7 days,big order usually 20-35 days, depending on orders quantity and whether are standard size. |
Payment Terms: | Visa /Mastercard/PayPal/Apple Pay/Google Pay |
Supply Ability: | All products have passed CE certification and comply with EU RoHS environmental standards |
Price: | $7-$50 |
Name: | Custom Ball Screw |
material: | S55C,SCM420H |
Nut type: | Single Nut$ Double Nut |
Application: | 3D Printer/CNC Machine |
core component: | Engine, Bearing, motor, Pressure vessel |
manufacturing process: | Rolled Thread |
Length: | 10-160mm |
Company Info. |
SXEGL Intelligent Technology Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
Customizable Ball Screw For CNC Robots Dust Proof Corrosion Resistant
SEXGL ground ball screws deliver unparalleled accuracy and durability in high-precision automation systems, trusted by global leaders like BYD (EV powertrain assembly) and BOE (LCD panel cutting robots) across North America, Europe, Southeast Asia, and South Korea.As a critical component for precision motion control in CNC machines, this ball screw provides stable and reliable transmission support for high-precision machining, high-speed cutting, and heavy-load operations through innovative design and material technology. It helps enhance the machining accuracy and production efficiency of machine tools.
Characteristics
Theory
Ball screws operate via recirculating ball bearings that roll
between the screw shaft and nut. As the screw rotates, the balls
circulate through helical grooves, transferring motion linearly.
This rolling-contact mechanism replaces sliding friction with
near-frictionless motion, reducing heat generation and power
consumption. Preload adjustments eliminate axial play, ensuring
zero backlash and enhanced positional accuracy.
Model no. | d | Lead | >> >Bead diameter | (Nut size) | Dynamic Rating Load( Ca) | Static Rating Load (Coa) | rigidity kgf/ μm | ||||||||
D | A | B | L | W | H | X | Q | n | |||||||
SFDCR2812-2.8 | 28 | 12 | 6.35 | 54 | 87 | 16 | 65.5 | 72 | 9 | 69 | M8×1 | 2.8×1 | 2752 | 5746 | 43 |
SFDCR2812-3.8 | 12 | 6.35 | 54 | 87 | 16 | 77.5 | 72 | 9 | 69 | M8×1 | 3.8×1 | 3579 | 7799 | 59 | |
SFDCR2812-4.8 | 12 | 6.35 | 54 | 87 | 16 | 89.5 | 72 | 9 | 69 | M8×1 | 4.8×1 | 4375 | 9851 | 74 | |
SFDCR2816-2.8 | 16 | 4.762 | 48 | 74 | 12 | 74.5 | 60 | 6.6 | 60 | M6×1 | 2.8×1 | 1855 | 3589 | 41 | |
SFDCR2816-3.8 | 16 | 4.762 | 48 | 74 | 12 | 90.5 | 60 | 6.6 | 60 | M6×1 | 3.8×1 | 2412 | 4871 | 55 | |
SFDCR2816-4.8 | 16 | 4.762 | 48 | 74 | 12 | 106.5 | 60 | 6.6 | 60 | M6×1 | 4.8×1 | 2949 | 6153 | 70 | |
SFDCR3210-2.8 | 32 | 10 | 4.762 | 58 | 91 | 18 | 57 | 76 | 6 | 68 | M8×1 | 2.8×1 | 1955 | 4041 | 45 |
SFDCR3210-3.8 | 10 | 4.762 | 58 | 91 | 18 | 67 | 76 | 6 | 68 | M8×1 | 3.8×1 | 2542 | 5485 | 61 | |
SFDCR3210-4.8 | 10 | 4.762 | 58 | 91 | 18 | 77 | 76 | 6 | 68 | M8×1 | 4.8×1 | 3107 | 6928 | 77 | |
SFDCR3205-2.8 | 5 | 3.175 | 50 | 87 | 16 | 39 | 72 | 9 | 69 | M8×1 | 2.8×1 | 1118 | 2653 | 43 | |
SFDCR3205-3.8 | 5 | 3.175 | 50 | 87 | 16 | 44 | 72 | 9 | 69 | M8×1 | 3.8×1 | 1454 | 3600 | 58 | |
SFDCR3205-4.8 | 5 | 3.175 | 50 | 87 | 16 | 49 | 72 | 6 | 69 | M8×1 | 4.8×1 | 1778 | 4547 | 73 | |
SFDCR3212-2.8 | 12 | 4.762 | 53 | 87 | 16 | 40.5 | 72 | 9 | 69 | M8×1 | 2.8×1 | 1956 | 4049 | 45 | |
SFDCR3212-3.8 | 12 | 4.762 | 53 | 87 | 16 | 64.5 | 72 | 6 | 69 | M8×1 | 3.8×1 | 2544 | 5496 | 61 | |
SFDCR3212-4.8 | 12 | 4.762 | 53 | 87 | 16 | 88.5 | 72 | 6 | 69 | M8×1 | 4.8×1 | 3110 | 6942 | 77 | |
SFDCR3216-2.8 | 16 | 6.35 | 57 | 87 | 16 | 77.5 | 72 | 6 | 69 | M8×1 | 2.8×1 | 2915 | 11226 | 48 | |
SFDCR3216-3.8 | 16 | 6.35 | 57 | 87 | 16 | 93.5 | 72 | 6 | 69 | M8×1 | 3.8×1 | 3790 | 8887 | 66 | |
SFDCR3216-4.8 | 16 | 6.35 | 57 | 87 | 16 | 109.5 | 72 | 9 | 69 | M8×1 | 4.8×1 | 4634 | 6549 | 83 | |
SFDCR4006-2.8 | 40 | 6 | 3.969 | 58 | 91 | 18 | 45.5 | 76 | 6 | 68 | M8×1 | 2.8×1 | 1671 | 4010 | 52 |
SFDCR4006-3.8 | 6 | 3.969 | 58 | 91 | 18 | 51.5 | 76 | 9 | 68 | M8×1 | 3.8×1 | 2172 | 5618 | 70 | |
SFDCR4006-4.8 | 6 | 3.969 | 58 | 91 | 18 | 57.5 | 76 | 6 | 68 | M8×1 | 4.8×1 | 2656 | 7096 | 88 | |
SFDCR4010-2.8 | 10 | 6.35 | 65 | 95 | 18 | 62.5 | 80 | 9 | 72 | M8×1 | 2.8×1 | 3192 | 9048 | 57 | |
SFDCR4010-3.8 | 10 | 6.35 | 65 | 95 | 18 | 72.5 | 80 | 6 | 72 | M8×1 | 3.8×1 | 4150 | 10922 | 77 | |
SFDCR4010-4.8 | 10 | 6.35 | 65 | 95 | 18 | 82.5 | 80 | 6 | 72 | M8×1 | 4.8×1 | 5074 | 13797 | 97 | |
SFDCR4012-2.8 | 12 | 6.35 | 65 | 95 | 18 | 65.5 | 80 | 9 | 72 | M8×1 | 2.8×1 | 3194 | 8058 | 57 | |
SFDCR4012-3.8 | 12 | 6.35 | 65 | 95 | 18 | 77.5 | 80 | 9 | 72 | M8×1 | 3.8×1 | 4153 | 10936 | 77 | |
SFDCR4012-4.8 | 12 | 6.35 | 65 | 95 | 18 | 89.5 | 80 | 9 | 72 | M8×1 | 4.8×1 | 5077 | 13815 | 97 | |
SFDCR4016-2.8 | 16 | 6.35 | 65 | 95 | 18 | 76.5 | 80 | 6 | 72 | M8×1 | 2.8×1 | 3198 | 8085 | 57 | |
SFDCR4016-3.8 | 16 | 6.35 | 65 | 95 | 18 | 92.5 | 80 | 9 | 72 | M8×1 | 3.8×1 | 4159 | 10972 | 77 | |
SFDCR4016-4.8 | 16 | 6.35 | 65 | 95 | 18 | 108.5 | 80 | 6 | 72 | M8×1 | 4.8×1 | 5084 | 13860 | 97 | |
SFDCR5010-2.8 | 50 | 10 | 6.35 | 75 | 118 | 18 | 62.5 | 100 | 11 | 92 | M8×1 | 2.8×1 | 3509 | 9982 | 67 |
SFDCR5010-3.8 | 10 | 6.35 | 75 | 118 | 18 | 72.5 | 100 | 11 | 92 | M8×1 | 3.8×1 | 4563 | 13547 | 90 | |
SFDCR5010-4.8 | 10 | 6.35 | 75 | 118 | 18 | 82.5 | 100 | 11 | 92 | M8×1 | 4.8×1 | 5578 | 17112 | 114 |
![]() |
