High Dielectric E3015 Encapsulated Transformers PCB Mount 5VA/6VA/8VA/9VA

E3015 PCB Mount Encapsulated Transformer 5VA/6VA/8VA/9VA with High Dielectric

Features:

• Safety transformer/short-circuit-proof
• Vacuum filled
• Split bobbin design
• Temperature class:40/B
• Dielectric strength: 4,500Vrms
• Weight: 75g
• With CE, UL, GS and RoHS marks
• OEM and ODM orders are welcome

• Supply samples free with short delivery time

Specifaction :

PART NO	Primary [V]	Secondary [V]	Current [mA]	Pin	No-Load Voltage [V]	Schematic No.
TG3005-E-0050-060-S	230v~	6	83.3	1+5/7+9	9.7	1
TG3005-E-0050-090-S	230v~	9	55.5	1+5/7+9	14.5	1
TG3005-E-0050-120-S	230v~	12	41.6	1+5/7+9	20.5	1
TG3005-E-0050-150-S	230v~	15	33.3	1+5/7+9	24.6	1
TG3005-E-0050-180-S	230v~	18	27.8	1+5/7+9	28.4	1
TG3005-E-0050-240-S	230v~	24	20.8	1+5/7+9	37.0	1
TG3005-E-0050-060-D	230v~	2× 6	2×41.6	1+5/6+7-9+10	2×10.1	2
TG3005-E-0050-075-D	230v~	2× 7.5	2×33.3	1+5/6+7-9+10	2×12.3	2
TG3005-E-0050-090-D	230v~	2× 9	2×27.8	1+5/6+7-9+10	2×15.6	2
TG3005-E-0050-120-D	230v~	2×12	2×20.8	1+5/6+7-9+10	2×19.9	2
TG3005-E-0050-150-D	230v~	2×15	2×16.6	1+5/6+7-9+10	2×23.3	2
TG3005-E-0050-180-D	230v~	2×18	2×13.8	1+5/6+7-9+10	2×27.9	2
TG3005-E-0050-240-D	230v~	2×24	2×10.4	1+5/6+7-9+10	2×37.2	2
TG3005-U-0050-060-S	115v~	6	83.3	1+5/7+9	9.7	1
TG3005-U-0050-090-S	115v~	9	55.5	1+5/7+9	14.1	1
TG3005-U-0050-120-S	115v~	12	41.6	1+5/7+9	20.5	1
TG3005-U-0050-150-S	115v~	15	33.3	1+5/7+9	24.6	1
TG3005-U-0050-180-S	115v~	18	27.8	1+5/7+9	28.4	1
TG3005-U-0050-240-S	115v~	24	20.8	1+5/7+9	37.0	1
TG3005-U-0050-060-D	115v~	2× 6	2×41.6	1+5/6+7-9+10	2×10.1	2
TG3005-U-0050-075-D	115v~	2× 7.5	2×33.3	1+5/6+7-9+10	2×12.3	2
TG3005-U-0050-090-D	115v~	2× 9	2×27.8	1+5/6+7-9+10	2×15.6	2
TG3005-U-0050-120-D	115v~	2×12	2×20.8	1+5/6+7-9+10	2×19.9	2
TG3005-U-0050-150-D	115v~	2×15	2×16.6	1+5/6+7-9+10	2×23.3	2
TG3005-U-0050-180-D	115v~	2×18	2×13.8	1+5/6+7-9+10	2×27.9	2
TG3005-U-0050-240-D	115v~	2×24	2×10.4	1+5/6+7-9+10	2×37.2	2
TG3005-U2-0050-060-S	2*115v~	6	83.3	1+2-4+5/7+9	9.7	3
TG3005-U2-0050-090-S	2*115v~	9	55.5	1+2-4+5/7+9	14.1	3
TG3005-U2-0050-120-S	2*115v~	12	41.6	1+2-4+5/7+9	20.5	3
TG3005-U2-0050-150-S	2*115v~	15	33.3	1+2-4+5/7+9	24.6	3
TG3005-U2-0050-180-S	2*115v~	18	27.8	1+2-4+5/7+9	28.4	3
TG3005-U2-0050-240-S	2*115v~	24	20.8	1+2-4+5/7+9	37.0	3
TG3005-U2-0050-060-D	2*115v~	2× 6	2×41.6	1+2-4+5/6+7-9+10	2×10.1	4
TG3005-U2-0050-090-D	2*115v~	2× 9	2×27.8	1+2-4+5/6+7-9+10	2×15.6	4
TG3005-U2-0050-120-D	2*115v~	2×12	2×20.8	1+2-4+5/6+7-9+10	2×19.9	4
TG3005-U2-0050-150-D	2*115v~	2×15	2×16.6	1+2-4+5/6+7-9+10	2×23.3	4
TG3005-U2-0050-180-D	2*115v~	2×18	2×13.8	1+2-4+5/6+7-9+10	2×27.9	4
TG3005-U2-0050-240-D	2*115v~	2×24	2×10.4	1+2-4+5/6+7-9+10	2×37.2	4

Application:

TIGER designs and manufactures a wide range of products for critical applications in various industries, including but not limited to:
· Automotive
· Consumer Electronics
· Industrial
· Medical
· Military & Aerospace
· Telecommunications
We are uniquely positioned to offer the highest quality products for critical applications as well as cost effective products for price sensitive applications.

Packing:

FAQ

1. Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: Sample order needs 7 days. Formal order needs 15-20 days.
3. Q: What's your payment terms?
A: We usually accept T/T at sight as the main payment terms, and other payment can also be negotiated.
4. Q: Do you have the prodcts in stock?
A: Yes,we will keep some general ones in stock.
5. Q: Can I mix different models in one container?
A: Yes,different models can be mixed up.

6. Q: Do you customize for customer or accept OEM Orders ?
A: Yes,we provide designing and customizing services. OEM orders are also accepted.
