| Categories | DMR Two Way Radio |
|---|---|
| Brand Name: | SUNTOR |
| Model Number: | ST30HPT |
| Certification: | CE、 SGS、RoHS |
| Place of Origin: | Shenzhen, China |
| MOQ: | 1 SET |
| Price: | Negotiation |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1500 set/ month |
| Delivery Time: | 7-15 days |
| Packaging Details: | ABS Plastic Box Paper Carton |
| Distance: | 30KM from Air to Ground |
| Weight: | 93g |
| Power: | 0.5Watts |
| Bandwidth: | 4MHz/8MHz |
| Dimension: | 76x73x23mm |
| Transmitting: | Double 3-6Mbps |
| Frequency: | 2.4GHz |
| Company Info. |
| Shenzhen Suntor Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
30KM Very Larger Range UAV Video Data Link Mavlink 1080P for Mapping Drone
30km Fixed Wing UAV Data Link Support Pixhawk High Definition Multimedia Interface Vido Input TTL Serial Ports
30KM Long Range UAV Data Link Fixed Wing Drones COFDM Transmitter and Receiver for Mapping Drones
Application
1. Mapping / GIS
2. Surveying
3. Complete UAV Mapping and Surveying Solutions
4. Mining
5. Line Inspection
Introduction:
SUNTOR
ST30HPT 2.4G Frequency very mini size UAV video data links COFDM transmitter and receiver.
Suntor ST30HPT mini transmitter receiver is a set of real-time image transmission system with mini High Definition Multimedia Interface and RJ45 Ethernet interface drone fixed wing. It converts the real-time signal from the mini High Definition Multimedia Interface camera into RF Power and send back to groud High Definition Multimedia Interface output wirelessly. The returned signal will be received by the accessary receiver and displayed on display screen.
Parameter
| Model: ST30HPT | ||||
| Frequency | 2.4GHz (2.402-2.478GHz) | Adjustable | ||
| RF Transmitting Power | ST30HPT: 33dBm | |||
| Frequency Bandwidth | 4MHz/8MHz | Adjustable | ||
| Size | 76×73x23mm | |||
| Transmission Rate | Double 3-6Mbps | |||
| Encryption | AES 128 | |||
| Transmission Mode | PTP | |||
| Start-up time | < 30s | |||
| Transmission Range | ST5NPT: Air to ground 30km | |||
| System Latency | 50-70ms | |||
| Interface Ports | RJ45 input/output Ethernet High Definition Multimedia Interface Video RS232 Serial Ports | |||
| Transmitting Rate | 100Mbps | |||
| Power | DC 7-18V | DC7~18V Optional | ||
| Power Consumption | TX:7W RX:6W | Maximum | ||
| Working Temperature | Operating temperature: -40 - 85°C Storage temperature: -55 - 100°C | |||
| Two-way function | Integrate multiple radio links into one to transmit and receive. Support SBUS/Mavlink/TTL communication module | |||
| Appearance Design | CNC technology/ double aluminum alloy shell with waterproof design | |||
| Antenna | 1TX 1RX Small Antenna | |||
| Net Weight | Tx:146g Rx: 146g | |||
Packaging:
1PCS Tx Antenna 19cm
1PCS Rx Antenna 29cm
1PCS Rx Antenna 14dBi
1PCS TPalyer Key
2PCS High Definition Multimedia Interface Cable
2PCS Feed Antenna Cable
3PCS RS 232 Serial Ports Cable
4PCS Power Cable
4PCS Ethernet Cable
4PCS TTL Data Cable
Warranty:
Products are warranted for 1 year from the date of package signed.
|
