Electrical vibroflot with powerful motor used for vibro piling engineering BJV130E-426
| The Top Feed Electric Vibroflot Spec. | ||||||||
| Type | Power (kW) | Rated current(A) | Max rotation speed(rpm) | Max amplitude (mm) | Vibration power(kN) | Weight (kg) | Outer diameter(mm) | Length(mm) |
| BJV130E-426 | 130 | 255 | 1450 | 17.2 | 208 | 2320 | 426 | 2963 |
vibroflot characteristics
The vibroflot barrel and the motor housing are made of high
strength forged steel
The motor coil adopts high temperature aging film envelop, long
service life and good insulation effect
Unique circulating water cooled motor structure, good heat
dissipation with high efficiency
Both vibroflot and motor are imported with FAG original bearing
Double-deck vibrating head design with good resistance, easy to
replace
Unique bearing oil lubrication, further improve bearing life
Vibroflot manufacturer profile (BVEM)
China first use of 75KW vibrator for the 30-meter depth sand soil
treatment(three gorges project)
China first use of hydraulic vibrator for the treatment of the
240-meter chimney foundation
China first use of hydulic vibrator for the treatment of 32m depth
foundation of hydraulic power station
The first one in China who treated the base of oil storage tank
with a diameter of more than 60m by vibroflotation method
|
