| Categories | Waterproof Walkie Talkies |
|---|---|
| Brand Name: | baofeng |
| Model Number: | S56 |
| Place of Origin: | China |
| MOQ: | 10pcs |
| Price: | USD23.00 |
| Payment Terms: | L/C, T/T, Western Union, T/T, Western Union |
| Supply Ability: | 50000pcs / year |
| Delivery Time: | 3-8 days |
| Packaging Details: | carton box |
| Type: | Handheld |
| output power: | 10W |
| channels: | 16 |
| frequency range: | 400-480MHZ |
| Dimensions:: | 62.5*123*36mm(Excluded Antenna) |
| Talk Range:: | 8-15km |
| Operating Voltage:: | 7.4V Li-ion |
| Battery capacity:: | li-ion 2800mAh |
| color: | black |
8-10KM Waterproof Walkie Talkies Long Distance S-56 10w Power 16 Channel UHF 400-480mhz
Features:
Output power :10W
Frequency range: FM 65 – 108 MHZ / UHF 400 – 480 MHZ
Channels:16
VOX Function
50 CTCSS and 105 DCS
Emergency Alarm
High/Low Power Select
Battery saving
FM broadcast 65-108MHZ
IP 67 waterproof and dustproof
PC programmable
Specification
| Frequency Range: | |
| 400.00- 480.00MHz | |
| Storage Channel | 128 |
| Step Frequency | 2.5 KHz,6.5 KHz,10 KHz,12.5 KHz,25 KHz |
| Rated voltage | DC 7.4V |
| Frequency Stability | ±2.5ppm |
| Work Temperature | -20 ℃ to +60℃ |
| Battery Capacity | H-2800m Ah (Li-ion Battery) |
| Battery Life | About 12 Hours |
| Frequency Combination | PLL frequency synthesis |
| Antenna Impedance | 50 Ω |
| Wok Mode | Same Frequency simplex Operation or Different Frequency simplex Operation |
| Dimension | 123(H)*62(W)*36(D)mm (Excluded Antenna) |
Transmitter
| Output Power | 10W |
| Modulation Mode(W/N Band) | 16KΦF3E |
| Maximum Frequency Deviation (W/N Band) | ≤5 KHz |
| Spurious Power | ≤7.5 µW |
| Adjacent channel power | ≤-65dB/≤-60dB |
| Audio Distortion | <5 % |
| SNR | ≥-45dB/≥-40dB |
| CTSCC/DCS Frequency Deviation(W/N Band) | 0.7±0.1KHz (W), 0.4±0.1KHz (N) |
| Modulation Sensitivity | 8-12mV |
| Transmitting Current | ≤1500mA |
Receiver
| Sensitivity | <0.20 µ V (12dB SINAD) |
| Audio Power | >2W@10% |
| Inter modulation Interference Resistance | ≥65dB (W), ≥55dB (N) |
| Adjacent channel Sensitivity (W/N Band) | ≥65dB (W), ≥55dB (N) |
| Audio Distortion | 5 % |
| Receiving Current | ≤ 380m A |
Packing items:
1 x Transceiver S56 output power 10W
1 x 7.4V 2800mAh Li-ion Battery
1 x Antenna
1 x Charger pack(Desktop charger + charger)
1 x Belt Clip
1 x Handstrap
1 x User's Manual
|
