Digital Circuit Breaker Analyzer , Dynamic Characteristics High Voltage Tester

Categories Circuit Breaker Analyzer
Brand Name: GDZX
Model Number: ZXKC-HB
Certification: ISO9001
Place of Origin: Hubei, China
MOQ: 1 Set
Price: $3,000.00 - $5,000.00 / Sets
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 500 Set/Sets per Month
Delivery Time: 7~10 work days
Packaging Details: In carton or wooden case
Product name: Circuit Breaker Dynamic Characteristics Analyzer
Power supply: AC 220V ± 10%;50Hz ± 2%
Voltage output: 25~265V continuous adjustable
Operating environment: -10~+50℃
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Digital Circuit Breaker Analyzer , Dynamic Characteristics High Voltage Tester


Digital Circuit Breaker Analyzer , Dynamic Characteristics High Voltage Tester


High voltage switch dynamic characteristics tester is specially developed and produced to test the dynamic characteristics of various high voltage switches, such as oil switches, vacuum switches and sulfur hexafluoride switches.


Features

1. Built in thermal printer, USB interface

2. Independent 6 or 12 contacts, can test and indicate connection status for user to check wiring.

3. Storage capacity up to 100 (H series: 6000-1000) sets of testing results

4. LCD display, H series with touch screen.

5. Powerful graphic function, can display waveform and measurement data simultaneously

6. Manual or auto test modes

7. Function C-O, O-C, O-C-O, test, reclosing test

8. Can measure vacuum contactor (single coil) parameters


Technique Parameter

1. Time measuring range 0.01ms~10000ms/20000ms

2. Velocity measurement: instant opening (instant closing) velocity, appointed time average velocity

3. Stroke measurement:

4. Multiple sensors for options. Liner sensor :50mm, resolution: 0.1mm, stroke 0.1~50mm

Liner sensor :300mm, resolution: 0.1mm, stroke 10~300mm

Liner sensor :500mm, resolution: 1mm, stroke 10~500mm

360 wire sensor : 360 degree,resolution:0.5 degree, stroke: 1mm~1000mm

6. Instrument power supply : AC 220V ± 10%;50Hz ± 2%

7. DC power supply: voltage output: 25~265V continuous adjustable

8. Mainframe volume: 360×250×140mm, H series 380×280×170mm

9. Operating environment: -10~+50℃

10. Relative humidity: ≤90%
