| Categories | LiDAR Scanning System |
|---|---|
| Brand Name: | Geosun |
| Model Number: | GS-260F Mobile LiDAR Scanning System |
| Certification: | CE, ISO |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiation |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 30 SETS/Month |
| Delivery Time: | 10-15 works days |
| Packaging Details: | Suit Case 520*420*230 mm |
| Industry: | Mounted on the Vehicle |
| Application: | City Construction |
| Beam: | 20 Beam |
| Laser brand: | HESAI Pandar |
| Company Info. |
| Wuhan Geosun Navigation Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
gAirHawk GS-260F Mobile LIDAR SCANNING SYSTEM
Mobile LiDAR Scanning System Application for City Construction
gAirHawk GS-260F is a kind of Mid-range, compact LiDAR point cloud data acquisition system, integrated HESAI Pandar laser scanner, GNSS and IMU positioning and attitude determination system, and storage control unit, is able to real-time, dynamically, massively collect high-precision point cloud data and rich image information. It is widely used in the acquisition of 3D spatial information in surveying, electricity, forestry, agriculture, land planning.
Pandar20B 20-Channel Mechanical LiDAR
Specification
| gAirHawk GS-260S | ||
| Item Name | System Parameters | |
Parameters | Weight | 1.9 kg (without camera) |
| Measuring accuracy | 0.1m/0.05m(@150m) | |
| Working temperature | -20℃~+60℃ | |
| Power range | 12 V- 24 V | |
| Consumption | 20 W | |
| Carrying Platform | DJI M300, M600 PRO | |
| Storage | 64 GB storage, maximum support 128GB TF card | |
Lidar Unit | Measuring Range | 0.3m-200m@10% Reflectivity |
| Laser class | 905nm Class1 (IEC 60825-1:2014) | |
| Laser line number | 20-Beam | |
| Max. range | 200 m | |
| Mix. range | 0.3 m | |
| Range accuracy | ±5cm (@0.3m~5m), ±2cm (@0.5m~200m) | |
| Scanning frequency | 10HZ, 20HZ | |
| data | Double echo 720,000 Points/Sec | |
| FOV | 360°, adjustable | |
| Laser sensor | HESAI Pandar 20B | |
| POS Unit | Update frequency | 200HZ |
| Heading accuracy | 0.017° | |
| Pitch accuracy | 0.005° | |
| Rolling accuracy | 0.005° | |
| Position accuracy | ≤0.05m | |
| GNSS signal type | GPSL1/L2 GLONASSL1/L2 BDS B1/B2a/B3 | |
| GNSS Motherboard | OEM 719 | |
| IMU | Sensoner STIM 300 | |
| Pre-processing software | POS software | Output information: position, speed, attitude |
| Point cloud software | Output point cloud data format: LAS format, custom TXT format | |
Application for Road Mapping
Package
It is packed by suit case with EVA material liner inside, then covered by hard carton box. It is suitable for air shipment and sea shipment.
|
