Two Axis Table Laser PCB Depaneling Machine

UV PCB Laser Depaneling Machine Precision Laser Cutting For Rigid Boards


Introduction:

This PCB Laser Depaneling equipment is integrated with high-stability and the best performance UV laser

generator.

This equipment delivers great working area focus, power distribution ratio and small thermal affection that gives small cutting width and high cutting quality during processing.

With sophisticated two-axis table and closed loop control module, it ensures fast cutting while maintaining micron magnitude of precision with modern technology of position sensors and CCD image capture application.


As boards become thinner, smaller and more sophisticated, these methods expose PCB parts to mechanical stress—resulting in board breakage and lowering throughput.


Traditional Depaneling Solution Disadvantages:

1. Lower quality of cuts

2. PCB damage due to accumulated debris

3. Constant need for new bits, dies and blades

4. Not useful for boards < 500 µ

5. Design limitation—inability to cut complex, multidimensional PCBs


Clean and Precise Cutting:

Lasers make clean, burr-free and precise cuts against the edge of circuits and other important components—improving overall design flexibility without damaging the substrate. Because you don’t have to reorder parts or sharpen bits and blade, laser systems are also more cost effective.


Specification:


LaserQ-Switched diode-pumped all solid-state UV laser
Laser Wavelength355nm
Laser SourceOptowave UV 15W@30KHz
Positioning Precision of Worktable of Linear Motor±2μm
Repetition Precision of Worktable of Linear Motor±1μm
Effective Working Field460mmx460mm(Customizable)
Scanning Speed2500mm/s (max)
Working field40mmх40mm
