| Categories | Optical Fiber Fast Connector |
|---|---|
| Brand Name: | Global Telecom |
| Model Number: | GT-006 |
| Certification: | CE/ROSH/IOS9001 |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500sets |
| Delivery Time: | 5-8 work days |
| Packaging Details: | stander packing |
| Type: | fast connector |
| No. of Fiber: | 1. |
| Use: | FTTH or FTTX, FTTx FTTH FTTB Network |
| Dimensions: | 50mm*8.9mm*7mm |
| Return Loss: | ≥50db |
| Working temperature: | -40℃~80℃ |
| Fiber: | 2.0*3.0 GJXH |
| Insertion cycle: | more than 1000 times |
| Insertion Loss: | ≤0.3db |
| Connector: | SC UPC/PC |
Factory wholesale SC IC FC UPC/APC fast connector fiber optic fast connector ftth sc/upc single mode quick connector
| Applicable for | Drop cable / Indoor cable |
| 0.9mm Tight Buffer Fiber, 2.0mm, 3.0mm Drop Cable | |
| Optical fiber diameter | SM(9/125), MM(50/125, 62.5/125) |
| 125μm ( 657A & 657B ) | |
| Tight buffer diameter | 250μm |
| Operation time | About 100s(no fiber cut) |
| Insert loss | ≤ 0.3dB(1310nm & 1550nm) |
| Return loss | > 50db(PC), > 55db(UPC), > 65db(APC) |
| Fastening strength of naked fiber | >5 N |
| Fastening strength of naked fiber holder | >10 N |
| Tensile strength | >50 N |
| Using temperature | -40~+75°C |
| On-line tensile strength (20 N) | IL ≤ 0.5dB RL ≤ 5dB |
| Mechanical durability (500 times) | IL ≤ 0.5dB RL ≤ 5dB |
| Drop-off test (drop-off height 4m,once per direction, totally 3 times) | IL ≤ 0.3 |
|
