| Categories | Industrial LED Flood Light |
|---|---|
| Brand Name: | KHJ |
| Model Number: | KSF36, KSF48, KSF56, KSF72 |
| Certification: | CE,RoHS |
| Place of Origin: | Guangdong, China |
| MOQ: | 1pcs |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 400pcs per day |
| Delivery Time: | 3-8 work days |
| Packaging Details: | 1234*281*165mm |
| Product Name: | Swordfish Series |
| Working Voltage: | 100-277 VAC/24-48 VAC;10-30 VDC/24-48 VDC/141-392 VDC |
| Watts: | 36W 48W 56W 72W |
| Luminaire Efficacy: | 136.5lm/W |
| Surge Protection: | 5KV |
| LED Driver: | Over voltage protection/short circuit protection |
| Weight: | 6.9Kg |
| Size: | 1130*187*125mm |
Industrial LED Flood Light, 4ft linear light,weather proof IP66
Industrial LED Flood Light, 4ft linear light,weather proof IP66
Highlight: 4ft linear light,weather proof IP66
Features And Benefits:
1. L70 rated for >100,000 hours.
2. 5 years full performance warranty.
3. Low glare.
4. Easy retrofit solution for exisiting flourescent fittings due to same size and fixing centres.
5. Instant start.
Product Important Information:
| Executive Standard | EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 |
| Certificate | CE, RoHS |
| Ambient temp | -20℃ ≤ Ta ≤ +55℃ |
| Ingress Protection | IP66 |
| Cable entry | M25*1.5(M20*1.5,3/4 NPT for optional) |
Applications:
Can be widely used for indoor and outdoor application and Where extremely corrosive, wet, dusty, hot and/or cold conditions exist
1. Shipping industry
2. Power transmission
3. Cement plants
4. Other outdoor and indoor safety area
Ordering information:
| P/N | Operating Voltage(V) | Luminous Flux(lm) | Power(W) | CRI | Color Temp. | CCT(K) |
| KSF361200H7V7WM-E | 100-277 AC (141-392 DC) | 4536 | 36 | 82 | Warm white | 3000±300 |
| KSF361200H7V7NH-E | 4914 | 36 | 70 | Natural white | 4000±300 | |
| KSF361200H7V7NH-E | 4914 | 36 | 70 | Natural white | 5000±300 | |
| KSF361200H7V7CH-E | 4914 | 36 | 70 | Cool white | 5700±300 | |
| KSF481200H7V7WM-E | 6048 | 48 | 82 | Warm white | 3000±300 | |
| KSF481200H7V7NH-E | 6552 | 48 | 70 | Natural white | 4000±300 | |
| KSF481200H7V7NH-E | 6552 | 48 | 70 | Natural white | 5000±300 | |
| KSF481200H7V7CH-E | 6552 | 48 | 70 | Cool white | 5700±300 | |
| KSF561200H7V7WM-E | 7056 | 56 | 82 | Warm white | 3000±300 | |
| KSF561200H7V7NH-E | 7644 | 56 | 70 | Natural white | 4000±300 | |
| KSF561200H7V7NH-E | 7644 | 56 | 70 | Natural white | 5000±300 | |
| KSF561200H7V7CH-E | 7644 | 56 | 70 | Cool white | 5700±300 | |
| KSF721200H7V7WM-E | 9072 | 72 | 82 | Warm white | 3000±300 | |
| KSF721200H7V7NH-E | 9828 | 72 | 70 | Natural white | 4000±300 | |
| KSF721200H7V7NH-E | 9828 | 72 | 70 | Natural white | 5000±300 | |
| KSF721200H7V7CH-E | 9828 | 72 | 70 | Cool white | 5700±300 |
|
