PIANC Standard D Type Fenders Natural Rubber Dock Buffers Bumpers

Categories D Type Fenders
Brand Name: DockFender
Model Number: DF-DH300
Certification: BV, ABS, SGS
Place of Origin: China
MOQ: 1 Piece
Price: USD170-2570 Per Piece
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2600 Pcs Per Month
Delivery Time: 5-7 Work Days
Packaging Details: Wooden Pallet, Wooden Case
Product Name: Dock Buffer H300 D Type Fenders PIANC Standard Natural Rubber Marine Mooring Buffer
Processing Service: Moulding, Cutting
Size: Customized
Function: Shock Absorption
Part: Dock Bumper
Age Range: 15-20 Years
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

PIANC Standard D Type Fenders Natural Rubber Dock Buffers Bumpers

Dock Buffer H300 D Type Fenders PIANC Standard Natural Rubber Marine Mooring Buffer


Description


Leading supplier for reasonably priced D Type Fenders and extrusion fenders to companies in countries in Asia, America and Africa. It is an attractive option due to its long-term durability and low cost. D type rubber fender is suitable for relatively smaller wharves and quays where it acts as a great protective medium for small/medium-sized vessel berthing. Common applications include for tug boats, fishing vessels, barges, marine work assets, small boats etc.


Specifications


MaterialSilicone Rubber, Natural rubber, EPDM, NBR, FKM, PU, etc
Product NameDock Buffer H300 D Type Fenders PIANC Standard Natural Rubber Marine Mooring Buffer
SizeDF-DH300
ShapeD Type
ColorTransparent, black, white, any pantone color is available
Temperature range-40℃~300℃
Hardness50 shore A~80 shore A
FeatureHigh temperature resistant; tear resistant, wear resistant; oil resistant; etc
MOQ1 Piece
SampleAvailable
Delivery timeNormally 3-5 days


ABCDEFHK
[mm][mm][mm][mm][mm][mm][mm][mm]
70301530458090 - 130200 - 300
1004515305010090 - 130200 - 300
12560204060125110 - 150250 - 300
15075204075150110 - 150250 - 300
150802550100200130 - 180300 - 400
2001002550100200130 - 180300 - 400
2001003060125250140 - 200350 - 450
2501253060125250140 - 200350 - 450
3001503060150300140 - 200350 - 450
3501753575175350140 - 200350 - 450
3801903575190380140 - 200350 - 450
3001503575175400140 - 200350 - 450
4002003575200400140 - 200350 - 450
5002504590250500160 - 230400 - 500
*Note: Other sizes can be customized according to the requirements.

ABCDEFGHK
[mm][mm][mm][mm][mm][mm][mm][mm][mm]
100251030151005090 - 130200 - 300
1503012652015075110 - 150250 - 350
20045157525200100130 - 180300 - 400
250502010030250125140 - 200350 - 450
300602512530300150140 - 200350 - 450
350702515035350175140 - 200350 - 450
400803017535400200140 - 200350 - 450
400803020035400200140 - 200350 - 450
5001003025035500250140 - 200350 - 450

Features


1. Higher volumes of energy absorption and reaction force than those of cylindrical fender.

2. Compact size and expedient installation.

3. The side for attachment is flat so that it can be secured more firmly than cylindrical fender.

4. Provide an excellent barrier against damage from all sizes and shapes of vessels.


Applications


● Workboats

● Tugboats

● Pilot Boats

● Fishing Boats

● Pontoons

● Shipping Quays

● Coast Guard, Naval, and Military ships


Rubber Properties


PROPERTIESTEST STANDARDVALUES
Compound-NR / SBR
Density (Specific Gravity)DIN 535051200 kg/m3
Tensile StrengthDIN 53504≥16 MPa
Elongation at BreakDIN 53504≥350%
Tear Resistance (23°C)DIN 53507≥80 N/cm
Abrasion ResistanceDIN 53516≤100mm3
Compression Set (24hrs @ 70°C)DIN 53517≤40%
Ozone Resistance (ppm 20% 72hrs @ 40°C)ISO 143/1No cracking visible by eye
Change In HardnessDIN 53504≤5°
Change In Tensile StrengthDIN 53504≥80%
Change In Elongation at BreakDIN 53504≥80%
Minimum Temperature--30°C
Maximum Temperature-+70°C

Advantages


1. Quality

DockFender D type fenders always maintain high quality. We insist on using 100% natural rubber, coupled with a special angle design, so that our D type rubber fenders can be more durable and perform better.


2. Service

DockFender adheres to the principle of customer first. Our professional customer service team can not only provide you with the most professional product recommendations, but also help you customize project solutions.


3. After-sales Service

DockFender 's fixed D type fenders can be guaranteed for 36 months. As long as you use it normally, we can guarantee replacement for any product quality problems during the warranty period.


4. Customize

All products of DockFender can be specially customized according to customer requirements, let us know your needs!


Material of main accessories


1. Bolt: Q235 hot-dip galvanised /1Cr13(2Cr13)1Cr18Ni9Ti/SUS304/SUS316

2. Washer: Q235 hot-dip galvanised.

3. Pre-built-in nut: 1Cr13(2Cr13)1Cr18Ni9Ti/SUS304/SUS316

4. Foot rod and board: Q235
