| Categories | Toros Mini Excavator |
|---|---|
| Brand Name: | TOROS |
| Model Number: | TE-26S |
| Certification: | CE\EPA\EURO 5 |
| Place of Origin: | China |
| MOQ: | 1 PCS |
| Price: | $18500-$19000 1 PCS |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, |
| Supply Ability: | 100 PCS/Week |
| Delivery Time: | 30 Work Days |
| Packaging Details: | Standard International Ocean Shipping |
| Total length*width*height (during transportation): | 3850*1300*2380 mm |
| Dozer blade width (extend/retract): | 1300/1500 mm |
| Dozer blade height: | 292 mm |
| Track center distance: | 1050/1250 mm |
| Bucket capacity: | 0.066 m3 |
| Displacement: | 1.116 L |
| Swing angle: | 75/55 ° |
| Gradeability: | 58（30）° |
| Bucket digging force: | 18.4 KN |
Hot selling mini excavators support factory customization
The one-year free warranty service for this model has started!
Click The Inquiry Below To Get The Best Price!
With closed cab has a more spacious working surface, which ensures the safety of the operators on the machine, and prevents the sudden stones and sundries from causing personal injury. It also allows the staff to have a warm and comfortable environment in the harsh working environment. It is suitable for small-scale earthwork engineering, municipal engineering, road repair, basement and indoor construction, concrete crushing, buried cables, laying of water pipes, garden cultivation and dredging of river channels.
| total measurement | ||||||||||
| Total length*width*height (during transportation) | 3850*1300*2380 mm | |||||||||
| Dozer blade width (extend/retract) | 1300/1500 mm | |||||||||
| Dozer blade height | 292 mm | |||||||||
| Track center distance | 1050/1250 mm | |||||||||
| Distance from the center of rotation to the tail of the track | 930 mm | |||||||||
| Standard track shoe width | 250 mm | |||||||||
| Minimum ground clearance | 170mm | |||||||||
| Standard bucket width (with/without side teeth) | 460 / 410 mm | |||||||||
| Track length | 1860 mm | |||||||||
| Wheel spacing | 1475 mm | |||||||||
| Scope of work | ||||||||||
| Maximum digging height | 3880 mm | |||||||||
| Maximum unloading height | 2550 mm | |||||||||
| Maximum digging depth | 2320 mm | |||||||||
| Maximum vertical boom digging depth | 1900 mm | |||||||||
| Maximum digging distance | 4140 mm | |||||||||
| Maximum digging distance on the ground | 4015 mm | |||||||||
| Minimum radius of gyration of the front section | 1850 mm | |||||||||
| The minimum radius of gyration at the rear end | 710 mm | |||||||||
| Maximum bulldozing height | 340 mm | |||||||||
| Maximum bulldozing depth | 270 mm | |||||||||
| Bucket moves horizontally to the left | 620 mm | |||||||||
| Bucket moves horizontally to the right | 590 mm | |||||||||
| Performance parameter | ||||||||||
| Total Weight | 2480 kg /2630 kg | |||||||||
| Bucket capacity | 0.066 m3 | |||||||||
| engine model | 3TNV76-F | |||||||||
| Displacement | 1.116 L | |||||||||
| rated power | 15KW/rpm | |||||||||
| Walking speed (high/low) | 2.4/4.2 KM/h | |||||||||
| Swing speed | 9.5 r/min | |||||||||
| Swing angle | 75/55 ° | |||||||||
| Gradeability | 58(30)° | |||||||||
| Ground pressure | 28.4(0.29) | |||||||||
| Bucket digging force | 18.4 KN | |||||||||
| Fuel tank capacity | 28 L | |||||||||
|
