PC LCD Screen Operated Glue Dispensing Machine for Wall, Gap & Sphere

Categories Glue Dispensing Machine
Brand Name: HSTECH
Model Number: HS-D331AB
Certification: CE
Place of Origin: China
MOQ: 1 pc
Price: Negotiable
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100pcs per week
Delivery Time: 5~7 work days
Packaging Details: Wooden package, with foam
Product name: AB Glue Dispensing Machine
Other name: 4 axis glue dispensing machine
XYZ working range: 300*300*100mm
XYZ Speed: Max 300mm/s
Glue mixing ratio: 1:1-10:1
Dispensing Precision: Glue Amount±1%, Glue Proportion±1%
Drive System: Stepping Motor + Timing Belt
Repeat accuracy: ±0.02mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

PC LCD Screen Operated Glue Dispensing Machine for Wall, Gap & Sphere

PC LCD Screen Operated Glue Dispensing Machine for Wall, Gap & Sphere


Machine feature
1. Can replace manual operation by high precision programming of dots, strips, arcs and patterns on different planes or curved surface.
2. Suitable for positioning of different jobs.
3. It supports graphics importing from computer, PLT files, TCF files and G code files.
4. Suitable for glue: Anaerobics, Coatings, Cyanoacrylates, White Glues, Epoxy Resin, Greases, Sealants, Silicones, Solder/Braze Pastes, Thermal Grease, Conductive Adhesive, Red Gum, UV Glue, AB Glue, Polyurethane Resin Adhesive, etc.

Specification


ITEMSPEC
Glue Mixing Ratio1:1-10:1/Customizable
Dispensing Speed10-150g/5s(based on 1:1 glue proportion)
Dispensing PrecisionGlue Amount±1%, Glue Proportion±1%
X/Y/Z Working Range300*300*100mm(Z axis can be rotated)
XYZ SpeedMax 300mm/s
Drive SystemStepping Motor + Timing Belt
Repeatability±0.02mm
PatternLines, Circles, Arcs, Continuous Paths, 3D Linear Interpolation
Potting PrecisionAmount±1%, Ratio:±1%
Operation MethodAuto
ProgrammingTeach Pendant
ControlBoard card
Leak-proof FunctionValve with Vacuum Device
Weight65kg
Dimension(L*W*H)716*585*645mm
Power Supply220V 50-60Hz 350W
