Hokuyo DMS-HB1-Z06 Specifications Optical Data Transmission Device

Name: Hokuyo DMSHB1Z06 Specifications Optical Data Transmission Device With DSub Connector Cable 2m Long
Brand: Hokuyo
Price: 1 USD

Overview

DMSHB1-Z06 is a lead wire 2m with d-subconnector 25 pin. in the cableassemblies, cable assembly othercategory.

Specifications

Model No.	DMS-HB1-Z06
Transmission distance	0 to 1.0m(Changeable by adjuster)
Directive angle	30 degrees(Full angle)
Transmission directions	SIDE-ON
Transmission capacity (Input/Output)	8 bit/8 bit
Transmission method	Half-duplex two-way transmission
Transmission time	40msec
Modulation method	Pulse modulation
Verification method	Parity check
Power source	24VDC(10 to 30V)
Current consumption	100mA Max.
Ambient illuminance	4,000lux or less
Ambient temperature/ humidity	-10 to 50 degrees C/85%RH or less
Vibration resistance	Double amplitude 1.5mm, 10 to 30Hz, Each 2 hour in X, Y and Z directions
Impact resistance	500m/s2 Each 10 times in X, Y and Z directions
Connection	D-sub connector 25 pins
Protective structure	IP64(Except for connector part)
