| Categories | Hokuyo Laser Sensor |
|---|---|
| Brand Name: | Hokuyo |
| Model Number: | DMS-GB1-Z28 |
| Place of Origin: | Japan |
| MOQ: | 1 |
| Price: | Negotiate |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100PCS/MONTHS |
| Delivery Time: | Negotiate |
| Packaging Details: | Carton |
| condition: | new and original |
| Manufacturer: | Hokuyo |
| Product No: | DMS-GB1-Z28 |
| Directive angle: | 30 degrees(Full angle) |
| Transmission method: | Half-duplex two-way transmission |
| Transmission distance: | 1.0m(Changeable by adjuster) |
| Transmission time: | 40msec |
| Ambient temperature/ humidity: | -10～50℃/ 85%RH or less |
| Company Info. |
| Xiamen ZhiCheng Automation Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Overview
This is a 8-bit type data transmission device with countermeasures
against disturbance light. Characteristics
against disturbance light is improved because optical filer(IR-82)
is attached to inner optical cover and light with
820nm or less of wavelength is shut out.
Specifications
| Model No. | DMS-GB1-Z28 |
| Transmission distance | 1.0m(Changeable by adjuster) |
| Directive angle | 30 degrees(Full angle) |
| Transmission directions | HEAD-ON |
| Transmission capacity (Input/Output) | 8 bits/8 bits |
| Transmission method | Half-duplex two-way transmission |
| Transmission time | 40msec |
| Modulation method | Pulse modulation |
| Verification method | Parity check |
| Power source | 24VDC(10 to 30V) |
| Current consumption | 100mA Max. |
| Ambient illuminance | 4,000lux or less |
| Ambient temperature/ humidity | -10～50℃/ 85%RH or less |
| Vibration resistance | Double amplitude 1.5mm, 10 to 55Hz, Each 2 hour in X, Y and Z directions |
| Impact resistance | 500m/s2 Each 10 times in X, Y and Z directions |
| Connection | D-sub connector 25 pins |
| Protective structure | IP64(excluding the connector) |
