1.5 - 3 Ton Backhoe Loader With 1m3 Front Load Bucket Capacity

Categories Backhoe Loader
Brand Name: Bilon
Certification: CE
Place of Origin: China
MOQ: 1-10pcs
Payment Terms: L/C, T/T
Supply Ability: 3000 Set/Sets per Month
Delivery Time: 30 days
Packaging Details: Nude
Dimension(Long * Breadth * High): 5920x2250x3770 mm
Rated Load: 2500kg/200kg
Engine model: Yuchai
Rated Power: 75kw
Front Load Bucket Capacity: 1m3
Operating Weight: 8200kg
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

1.5 - 3 Ton Backhoe Loader With 1m3 Front Load Bucket Capacity

1.5Ton,3Ton Chinese Mini Backhoe Loader


The machine is of compact structure and logical layout. With beautiful apearance and design of

components embody hommization adequately.

- The performance has achieved advanced level in China. Using domestic famous brand hydraulic

system and imported transmission system for loader.

- The professional designed operation system as well as reasonable layout realies comfortable,

convenient and labor-saving operation, the steering axle with big swing angle and steering angle.

- It can be fixed with many accessories according to requirements!


Main Parameter


Operating Weight8200KG
Overall Dimension (L*W*H)5920×2250×3770
Wheel base2200mm
Min. Ground Clearance300mm
Bucket Capacity1.0m3
Breakout Force38KN
Loading lifting Capacity2500kg
Bucket Dumping Height2742mm
Bucket Dumping Distance925mm
Digging Depth52mm
Backhoe Capacity0.3 m3
Max. Digging Depth4082/4500mm
Swing Angle of Excavator Grab190o
Max. Pulling Force39KN

ENGINE


ModelYuchaiYC4A105Z-T20
TypeIn Line Direct injection Four-Stroke and Injection Combustion Chamber
Cylinder-Inside Diameter-Stroke4-105*120
Rated Power75KW
Rated Speed2400r/min
Min.Fuel Consumotion≤242g/km.h
Max. Torque≥252N.M
Displacement4.4L

Cheap 1.5 - 3 Ton  Backhoe Loader With 1m3 Front Load Bucket Capacity for sale
