Medical Waterproof Endoscope CCD Camera 700 Linear Two - Channels Output

Categories Endoscopy Camera System
Brand Name: STATEMED
Model Number: STT9-CCD10
Certification: CE, ISO
Place of Origin: CHINA
MOQ: 1 Set
Price: competitive
Payment Terms: L/C, T/T, Credit card, Western Union
Supply Ability: 300 Sets per month
Delivery Time: 10 working days after payment
Packaging Details: carton, wooden case
Product Name: Endoscope CCD Camera
White balance range: 200-15000''K
Image sensor: SONY SUPER HAD CCD
The output pixels: PAL:795(H)*598(V)
Scanning system: PAL:752lines,50field/sce
Signal-to-Noise: ≥52dB
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Medical Waterproof Endoscope CCD Camera 700 Linear Two - Channels Output


CE Approved Medical Waterproof Endoscope CCD Camera 700 Linear


Main Parameters

● High definition: 1/3 CCD. The horizontal definition achieves 700 TV lines. (PAL 795H*596V)
● Easy operating: DSP adjustment.
● Convenience: CCD camera adopts separate model design. The CCD is with waterproof structure.
● Two-channels output: Video signal adopts BNC Two-channels for 1.0Vp-p signals.
● Convenient power supply: 110-220V×10% input,50-60 Hz
● Watt: 25VA.

Camera
1/3''D
Pelx H×V
795H×598V 410,000
Horizontal definition
700TV lines
Scan system(Either)
752line/50 field /sec
Minimum illumination
0.5 lux XF 2.0
Synchronization manner
Inner-synchronization
Signal-to-Noise
≥52dB
Plus control
Automatic
Video output
1.0Vp-p, 75Ωcomplex signal
Adapter(Either)
OES or rigid
Connection Cable
2.5m normal. And special length needs order.
Power
AC220/110+10% 50Hz-60Hz
Watt
25VA
Deposited temperature
-20℃~+50℃
Work temperature
-10℃~45℃
Work humidity
20~85%
Function
Camera, white balance, video output, the waterproof grade of camera up to IPX7.



Packing
Packing List

Name
Quantity
Mainframe
1
camera [PAL]
1
Video line

2
power cable
1
optics coupler
1
manual
1


Packing by export carton
