Brand Name: | 3Arubber |
Model Number: | 3A3006 |
Certification: | RoHS/FCC/SGS |
Place of Origin: | China |
MOQ: | 1000 rolls |
Price: | negotiation |
Payment Terms: | L/C, T/T, Western Union,Paypal |
Supply Ability: | 10000000 rolls per month |
Delivery Time: | 10 working days after recieved your payment |
Packaging Details: | Packed in cartons |
Material: | pure PTFE expand |
Color: | white,yellow,red |
Quality: | FDA grade |
Density: | 0.15-0.5g/cm³ |
Working temperature: | -150℃-+250℃ |
Thinkness: | 0.075-0.2mm |
Width: | 3-100mm |
Length: | 6-50m |
Company Info. |
SANHE 3A RUBBER & PLASTIC CO., LTD. |
Verified Supplier |
View Contact Details |
Product List |
High Tensile Strength PTFE Expand Tape,PTFE Expand Tape for Industrial Seal with All Kinds of Color
CHEMICAL RESISTANCE:
Resistant to all media in the range of pH 0—14, except for molten or dissolved alkali metals and elemental fluorine at high temperatures and pressures
RESISTANCE TO AGEING:
The product is not susceptible to ageing in the permitted application range and can be stored indefinitely.
KEY FEATURES:
1 Made from 100% expanded PTFE(ePTFE)
2 High chemical and thermal resistance
3 Resistant to ageing
4 Physiologically safe
5 High strength
KEY BENEFITS:
1 Increased residual gasket stress
2 Greater blow-out resistance
3 High operating safety
4 Wide spectrum of applications
5 Reliably seals practically all media in the pH range 0—14
6 Highly conformable to the sealing surface
7 Straightforward installation
Specifications:
material | pure PTFE dispersion resin |
color | white, FDA grade |
adhesive | backing adhesive or not |
surface | smooth |
cross section | rectangle, round |
tensile strength | 8Mpa |
hardness | 30-70shore A |
density | 0.7-1.0g/cm3 |
creep relaxation | 70% |
volatility | 1.0% |
PH | 0-14 |
working pressure | 1.6Mpa in gas, 6.4Mpa in liquid |
working temperature | -168°C ~ +280°C(maximum +315°C) |
thickness | 1.5-7.0mm |
width | 2.0-1500mm |
length | 1.5-25m |
![]() |
