| Categories | RJ45 Lan Jack |
|---|---|
| Place of Origin: | DongGuan of China |
| Brand Name: | DGKYD |
| Certification: | RoHS/CE/UL/FCC/CE/ISO9001/ISO14001 |
| Model Number: | KRJ-0073NL |
| MOQ: | 1 piece |
| Price: | Please contact us to get the latest price. |
| Packaging Details: | Tray in Carton |
| Delivery Time: | 10 days |
| Payment Terms: | T/T, D/P, D/A, L/C, Western Union, MoneyGram |
| Supply Ability: | 100K pcs/day |
| Product Name: | Magnetic Jack, Modular Jack 8/8, RJ45 |
| Grounding to PCB: | Yes |
| Shielded: | Yes |
| Magnetic: | Yes |
| Company Info. |
| Keyouda Electronic Technology Co.,ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
| Part Number | KRJ-0073NL | Brand | DGKYD/OEM/ODM |
| Product Type | Connector-Modular | Connector Style | Jack |
| Jack Type | RJ45 | Connector Type | Modular Jack |
| Latch Style | Standard | Latch | Down |
| Filter | With Filter | LED Option | Without LED |
| Shielded | Yes | Applies To | Printed Circuit Board |
| Performance Speed | 10/100 BASE-TX | Grounding Options | Panel Ground and PCB Ground |
| Port Configuration | Single | Number of Positions | 8 |
| Jack Configuration | 1 x 1 | Terminals per Port | 8 |
| Shield Material | Copper Alloy preplated with Nickel | PCB Mounting Orientation | Side Entry (Right Angle) |
| Contact Mating Area Plating Material | Gold 6u/15u/30u/50u | Contact Base Material | Phosphor Bronze |
| Solder Tail Contact Plating Material | Tin-Lead over Nickel | PCB Mounting Style | Through Hole |
| Housing Material | PBT Polyester | Housing Color | Black |
| Operation Temperature | -40℃ to +85℃ | UL Flammability Rating | UL 94V-0 |
Note: RJ45 ,in order to keep good touch between gold finger and crystal head,should paint the gold on the
surface,there is 6u,15u,30,50u,usually use 6u,according to customer’s request and cost to proceed, gold finger
insert and pull life should be 750 times above.
