Place of Origin: | China |
Brand Name: | CNOEC, OPTO-EDU |
Certification: | CE|Rohs |
Model Number: | A11.1106 |
MOQ: | 1 pc |
Price: | Negotiation |
Packaging Details: | Carton Packing, For Export Transportation |
Delivery Time: | 5~20 Days |
Payment Terms: | T/T, West Union, Paypal |
Supply Ability: | 5000 pcs/ Month |
Applications: | Hobby|Home |
Drawtube: | Binocular|Monocular |
Illumination: | LED |
product name: | Microscope |
Theory: | Biological Microscope |
Company Info. |
Opto-Edu (Beijing) Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
Specifications:
A11.1106 Biological Microscope | -A | -B | -C | -D | |
Head | Monocular Head,45° inclined,360° Rotatable | ● | ● | ● | - |
Sliding Binocular Head,45° inclined,55mm-75mm | - | - | - | ● | |
Eyepiece | WF10X/18mm | ● | ● | ● | ● |
Objective | Achromatic 4X | ● | ● | ● | ● |
Achromatic 10X | ● | ● | ● | ● | |
Achromatic 40X, Spring | ● | ● | ● | ● | |
Achromatic 100X, Spring | - | - | ● | ● | |
Nosepiece | Triple Revolving Nosepiece | ● | ● | - | - |
Quadruple Revolving Nosepiece | - | - | ● | ● | |
Stage | Plain Stage with Specimen Clips, Size120x120mm | ● | ● | - | - |
Mechanical Stage,60mmx30mm | - | - | ● | ● | |
Condenser | N.A.=0.65, with Disc Diaphragm | ● | - | - | - |
N.A.=0.65, with Iris Diaphragm | - | ● | - | - | |
Abbe Condenser N.A.=1.25, with Iris Diaphragm & Filter | - | - | ● | ● | |
Focusing | Seperate Coarse & Fine Focusing Knobs | ● | ● | ● | ● |
Light Source | Incandescent Lamp220V/20W or 110V/20W or Fluorescent | ● | ● | - | - |
Halogen Bulb 6V/20W,AC 220V/110V | - | - | ● | ● | |
Optional Accessories | |||||
Eyepiece | WF16X | ||||
P16X | |||||
Objective | Achromatic 20X | ||||
Achromatic 60X(S) | |||||
Light Source | LED |
![]() |
