Caltta KIRISUN 2 Way Walkie Talkie Explosion Proof Dustproof Rainproof Digital Mode Compatible Walkie Talkie

Categories Caltta KIRISUN Two Way Radio
Brand Name: Caltta
Model Number: PH600
Certification: -
Place of Origin: China
MOQ: 2
Price: US $356.63
Payment Terms: L/C D/A Western Union D/P T/T MoneyGram Paypal
Supply Ability: 100 Piece/Pieces 7days
Delivery Time: 7-15 work day
Packaging Details: 25*20*10cm Piece/Pieces
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Caltta KIRISUN 2 Way Walkie Talkie Explosion Proof Dustproof Rainproof Digital Mode Compatible Walkie Talkie

General
Digital ProtocolETSI TS 102 361-1,-2,-3
Frequency

UHF1: 400-470MHz

UHF3: 350-400MHz

VHF: 136-174MHz

Channel Capacity32
Zone Capacity2
Channel Spacing12.5KHz/20KHz/25KHz
Frequency Stability±0.5ppm
Operating Voltage7.4V
Battery Capacity2600mAh (Standard)
Battery Life(5:5:90)

Analog: 16 hours

Digital: 20hours

Size (H x W x D)100*54.5*37.5mm (without antenna)
WeightAbout 270g (With Antenna and Battery)
Voice AnnouncementSupport
VocoderAMBE++
VOXSupport
Man DownSupport
VibrationSupport
Optional BoardSupport
RecordingSupport (Optional)
BluetoothBuilt-in BT4.0 Chip Supports BT Audio/PTT/Positioning Device (Optional)
LocationGPS (Optional)
EncryptionSupport SW and HW Encryption ( Optional )

Receiver


Sensitivity(Analog Typical)0.18uV(12dB SINAD)
Sensitivity(Digital Typical)0.18uV (5% BER)
Adjacent Channel Selectivity60 dB@12.5KHz/70 dB@20/25KHz (TIA603A)
60dB@12.5KHz /70 dB@20/25KHz ( ETSI )
Intermodulation70 dB (TIA603D)
65 dB (ETSI)
Spurious Rejection70 dB (TIA603D)
70 dB (ETSI)
Blocking or Desensitization80dB(TIA603D)
84dB(ETSI)
Co-channel Rejection-12~0 dB @12.5KHz/-8~0 dB @20/25KHz
Hum and Noise-40 dB@12.5KHz /-43 dB@20KHz /-45 dB@25KHz
Rated Audio Power0.5W
Max Audio Power2.0W
Audio Distortion @ Rated Audio≤3%
Audio Response+1~-3dB (TIA603D)
Conducted Spurious Emission-57 dBm (TIA603D)
Transmitter
Low Power Output1W
High Power Output4W (UHF1&UHF3) / 5W (VHF)
FM Modulation12.5KHz: 11K0F3E / 20KHz: 14K0F3E / 25KHz: 16K0F3E
4FSK Digital Modulation12.5KHz Data Only: 7K60F1D&7K60FXD
12.5KHz Voice Only: 7K60F1E&7K60FXE
12.5KHz Voice And Data: 7K60F1W
Conducted/Radiated Emission-36dBm ≤1GHz ; -30dBm >1GHz
Modulation Limiting±2.5KHz @12.5KHz /±4KHz @20KHz /±5.0KHz @25KHz
FM Hum and Noise-40 dB@12.5KHz /-43dB@20KHz /-45 dB@25KHz
Adjacent Channel Power60 dB@12.5KHz /70 dB @20/25KHz
Audio Distortion @ Rated Audio≤3%
Audio Response+1~-3dB(TIA603D)
Environmental
Operating Temperature-30℃ ~ +60℃
Storage Temperature-40℃ ~ +85℃
ESDIEC 61000-4-2 (level 4) ±8kV (Contact) ±15kV(Air)
Dust and Water ResistanceIP68
ReliabilityMIL-STD-810 G
GPS
Accuracy specs are for long-term tracking (95th percentile values>5satellites visible at nominal -130 dBm signal strength)
TTFF (Time To First Fix) - Cold Start<60s
TTFF (Time To First Fix) - Hot Start<10s
Horizontal Accuracy<10m



Tks your kindly inquiry.

May i know the quantity and frequency you need?

And do you have forwarder in china?

Mine whaqtsapp is +8613539768762,how about yours?

Waiting.



Incredible audio quality
There is no doubt that digital walkie-talkies can get a clearer picture of voice calls.
The GP338D handheld walkie-talkie can provide you with excellent digital audio performance in the coverage area, and its unique features can help employees speak clearly and clearly wherever they are.
Intelligent audio can automatically adjust the volume of the radio, compensation background noise, so the workers don't have to adjust the volume of the radio can be avoid in noisy environment, missed call or disturb others when quiet area.
Enhanced background noise suppression helps to filter out unwanted external noise - from the noise emitted by heavy equipment to the roar of the engine.

Oversize and coverage
Employees work hard every day - hauling heavy loads, repairing roads, providing security, responding to customer demands, or restoring power after a storm.
Interconnect IP base station by using the Internet to expand coverage to create a wide area network, will expand the coverage of a single base station or geographically dispersed base station connected together, which helps greatly improve customer service and increase productivity.
Capacity Plus (cluster extension) single base station cluster solution, which can extend the communication Capacity to more than 1000 users without adding new frequencies.
Linked Capacity Plus combines the expansion Capacity of Capacity Plus with the wide coverage of IP base station interconnection to provide multi-base cluster solutions with high Capacity, wide coverage and efficient economic performance.
Therefore, whether you want to use a single base station or a multi-base station, MSTAR can meet your business and budget needs.
