Multi Functions Digital Label UV Printing and Varnishing Machine

Categories Label Printing Machine
Brand Name: ECOOGRAPHIX
Model Number: Label Modular
Certification: CE
Place of Origin: CHINA
MOQ: 1SET
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 300SET
Delivery Time: about 20days
Packaging Details: standard export packing
Resolution: 1200*600 dpi
Printing speed: 10m/min - 75m/min
Variable Image system: PDF,Optional barcode system
Substrates: PET film,Coated paper, Synthetic paper, Art paper, etc
Warranty: One Year
Weight: 2800KGS
Print Colors: CMYK/W+CMYK/W+W+CMYK
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Multi Functions Digital Label UV Printing and Varnishing Machine

6 Colors Digital Label Machine Uv Inkjet Label Printer


Label Smart is specially designed for small batch, multi-batch, personalized variable data label printing, with low investment cost and the best efficiency and effectiveness.

It has a wide range of applications, whether it is film (PET, BOPP, PE, BOPA), label paper (PE label), pre-pressed material (PET, ALU, PE) or paper and other materials, Label Smart 216S can easily handle it, helping customers win diversify the label market.

Label Smart has the Large roll feeding, anti-collision induction, web guide, double-sided dust removal, corona unit, mark tracking electric eye, LED curing, intelligent industrial control, water cooling system are all available; it is equipped with imported high-precision industrial nozzles, which can be used in four colors according to the actual needs of customers.


On the basis of adding white ink configuration, it achieves a maximum full-color printing speed of 50m/min and a maximum resolution of 600×1200dpi. The colors are accurate and stable, and can be adapted to a variety of printing materials; using Agfa environmentally friendly ink, the printed matter is rich and colorful No odor.


2 ) The advantages of UV Inkjet Printing Press


● 6-color digital printing, covering 95% of Pantone colors

● New upgraded design, simple operation

● Fully automatic integrated program to improve efficiency

● Built-in quality inspection device, real-time color inspection and quality control

● Support remote operation and maintenance

● Upgrade printing control software to optimize production process


ModelEcoo Label Modular 330
Printing TechnologyPiezoelectric Inkjet
Print MethodRoll to Roll, One -Side
Color ConfigurationSupport up to 8 colors
Number Of Channels8
Maximum Speed50m/min(CMYK); 25 m/min(CMYK+W)
Resolution600x600 dpi/600 x1200 dpi
Ink TypeUV Ink
Curing MethodUV LED + Mercury lamp
Media Width150-350mm
Maximum Print Width324mm
Media Thickness50-400um
Media TypePET, BOPP, PE, BOPA PP, Coated paper, Synthetic paper, Art paper, etc
Maximum Media Roll Diameter700 mm
Power supply380V
Power30kw
Compressed air>6.5MPa
Air consumption>10L/min
Operating environmentTemperature: 20℃-27℃, Humidity: 40%-70% relative humidity
Skew Adjustment Systemyes
Electrostatic Dust Removalyes
Water Cooling Systemyes
Coating Unitoptional
Digital Varnishingoptional
Cold Foil Stampingoptional
Hot Foil Stampingoptional
Visual inspectionoptional
