Private Mold 910Pro 6-channel Wireless Interphone System with Full Duplex Communication

Categories Wireless Intercom System
Private Mold: Yes
Place of Origin: Beijing, China
Brand Name: TYSTVideo
Model Number: TY-910Pro6
Name: Full-duplex wireless intercom system
Frequency Range: 420MHZ~480MHZ
Transmission distance: 1500 meters
Max transmission distance: 3000m with relay (optional)
Certification: ISO4001 and ISO9001
Receiving sensitibity: ≤93dBm
Power consumption: <1W
Singal-to-noise ratio: >50dB
Total harmonic distortion: <3%
Voltage: Host: AC100-240V; Beltpack: 5V
Price: $2,022.00/sets 1-4 sets
MOQ: 1 set
Delivery Time: Around 8 days
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Private Mold 910Pro 6-channel Wireless Interphone System with Full Duplex Communication

Product Description
Full duplex wireless communication system
Technical Specifications
1. One host + 7 extensions + 1 relay for multi-party calls, real-time relay forwarding to increase transmission distance.
2. Ultra-low call delay, single-microphone intelligent noise reduction algorithm to improve call quality in noisy environments.
3. AES128 communication encryption, support 6-digit custom call password to stop crosstalk between the same product and the same
frequency.
4. LCD screen display via which users can adjust the settings, such as channel number, extension number, power, communication
password, language and other options.
5. Frequency range: 420-480MHZ, number of channels 99.
6. Transmitting power: host 1W/2W (optional), extension 0.5W/1W (optional).
7. Support IP network calls, support AUX IN, AUX OUT, 2W, 4W audio interfaces, parallel port high and low level TALLY signals and
vMix & Blackmagic switchers.
8. Working current: host 330mA/5V (without voice call), extension 170mA/4.2V (without voice call)


Host
Extension
Supply voltage
100-240V AC input 50/60Hz
4000mAh, polymer lithium battery
Receiving sensitivity
≤-93dBm
≤-93dBm
Power consumption
<1W
<1W
Size
482 x 45 x 215mm (including antenna interface)
65 x 27 x 163mm (including antenna height)
Working frequency
420-480MHz digital frequency;
Signal to noise ratio
>50dB
Temperature range
-20~60℃
Total harmonic distortion (THD)
<3%
Product details


Exhibition Glimpse
Company Introduction



Packing&Shipping
We have a factory specializing in the production of flght boxes, all the products can provide the corresponding flight boxes,so as to be carried at ordinary times.
If you have video and audio equipment or other sophisticated equipment need to customize the flight case, we are the right choise !!!
