Warranty: | 2 years |
Place of Origin: | Guangdong, China |
Brand Name: | Eaton |
Model Number: | 9395 |
Phase: | Three Phase |
Protection: | Short Circuit |
Weight: | 1000kg |
Type: | On-line |
Application: | Data Center |
Electric Energy: | 600 Wh |
Product name: | Eaton Power Xpert 9395 |
Power level: | 200 to 1200 kVA |
Rated voltage: | 380 / 400 / 415 / 480V |
Product type: | Modular UPS |
Frequency: | 50 / 60 Hz |
Efficiency: | 99% |
Input Voltage: | 480V standard 600/575V and 400/415V optional |
Output Voltage: | 480V standard 600/575V and 400/415V optional |
Inverter: | Inverter |
Certifications: | CB ,IEC 62040-2,C3 limits |
Price: | $35,000.00/units 1-4 units |
Company Info. |
Visench Technology Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
Product name | Eaton Power Xpert 9395 |
Power level | 200–1200 kVA |
Rated voltage | 380 / 400 / 415 / 480V |
Product type | Modular UPS |
Frequency | 50 / 60 Hz |
Efficiency | 99% |
Input Voltage | 480V standard; 600/575V and 400/415V optional |
Output Voltage | 480V standard; 600/575V and 400/415V optional |
Inverter | PWM with IGBT switching |
Battery types | VRLA, AGM, wet cell, lithium-ion |
Battery voltage | 480V |
Control panel (LCD) | Color touchscreen |
System bypass module | Included |
Certifications | CB ,IEC 62040-2,C3 limits |
![]() |
