Duplex Stainless Steel Sheet Duplex Stainless Steel 2205 0.5 - 40.0mm Cold Rolled & Hot Rolled

Duplex Stainless Steel Sheet Duplex Stainless Steel 2205 0.5 - 40.0mm Cold Rolled & Hot Rolled

Products Specification

Standard Size of our 2205 Duplex Stainless Steel Plate in Stock

2205 duplex stainless steel 2205
2205 is a duplex (austenitic-ferritic) stainless steel containing about 40 - 50% ferrite in the annealed condition. 2205 has been a practical solution to chloride stress corrosion cracking problems experienced with 304/304L or 316/316L stainless.
The high chromium, molybdenum and nitrogen contents provide corrosion resistance superior to 316/316L and 317L stainless in most environments.
2205 is not suggested for operating temperatures up to 600°F.

The design strength of 2205 is significantly higher than 316/316L, often permitting lighter wall construction.
2205 has good notch impact toughness down to temperatures below - 40°F. 2205 is welded with E2209 or ER2209 fillers.
Chemistry

Specifications

ASME SA 182, ASME SA 240, ASME SA 479, ASME SA 789, ASME SA 789 Section IV Code Case 2603
ASTM A 240, ASTM A 276, ASTM A 276 Condition A, ASTM A 276 Condition S, ASTM A 479, ASTM A 790
NACE MR0175/ISO 15156
NORSOK MDS D45 Grade F51
UNS S31803, UNS S32205
W. NR./EN 1.4462

Type of our Duplex 2205 Stainless Steel Products

2205 Coil, 2205 Pipe, 2205 Plate, 2205 Sheet, 2205 Welding Products

Common Trade Names

2205 Stainless, Duplex 2205

Features
High resistance to chloride stress corrosion cracking
Chloride pitting and crevice corrosion resistance superior to 317L stainless
Good general corrosion resistance
High strength
Good sulfide stress corrosion resistance
Useful up to 600°F

Applications

• Chemical process vessels, piping, and heat exchangers
• FGD scrubber systems
• Pulp mill digesters, bleach washers, chip presteaming vessels
• Food process equipment
• Oil field piping, heat exchangers

Physical Properties
Density: 0.278 lb/inch3
Melting Point: 2525- 2630°F
Poisson's Ratio: 0.3
Electrical Resistivity: 481 Ohm - circ mil/ft

* 70°F to indicated temperature.
Mechanical Properties
Minimum Specified Properties, ASTM A 240

Minimum Elevated Tensile Properties, Plate

Corrosion Resistance

Our company is located in Wuxi City, China, we are a stainless steel plate, seamless steel pipe, round steel, steel belt, decorative pipe and other products distribution wholesale private enterprise. Our company operates stainless steel plate, seamless steel pipe, round steel, steel belt, decorative pipe best-selling consumer market. Without our products among consumers enjoy a higher status, the company with a number of retailers and agents to establish a long-term stable cooperative relationship. Our distribution of stainless steel plate, seamless steel pipe, round steel, steel belt, decorative pipe variety complete, reasonable price. The strength of the company, heavy credit, abide by the contract, ensure product quality, with a variety of management characteristics and the principle of small profits, to win the trust of our customers.
