Categories | Blend Polyols |
---|---|
Brand Name: | VICUS-VIDA |
Model Number: | VP-IR |
Certification: | ISO9001 |
Place of Origin: | China |
MOQ: | 1000 kg |
Price: | Negotiable |
Payment Terms: | T/T, L/C, Western Union, MoneyGram |
Supply Ability: | 10000 Tons/Year |
Delivery Time: | Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays |
Packaging Details: | 220 KGS/DRUM ,1000KGS /IBC TANK OR ISO TANK |
Model NO.: | VP-IR |
Specification: | Steel drum |
Trademark: | VICUSVIDA |
Origin: | China |
HS Code: | 3907299090 |
CAS No.: | 9003-11-6 |
Formula: | C5h10o2 |
EINECS: | 618-355-0 |
Molecular Principal Chain: | Carbon Chain Polymer |
Transport Package: | Steel Drum .IBC tank ,ISO Tank |
Customization: | Available | Customized Request |
Viscosity: | 1000-2000 mPa.s |
Function: | Flame Resistance, Heat Resistance |
Water Content: | Max 0.1% |
Functionality: | 2-3 |
Compatibility: | Compatible with most polyols and isocyanates |
Gel Time: | 6-10 Seconds |
Model No: | VS-08 |
Loading: | 80 Drums/20′fcl |
Free Rise Desity: | 31-32 Kg/M3 |
Density: | 1.1-1.2 g/cm3 |
Cas No: | 9016-87-9 |
Company Info. |
Vida New Material Technology Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
VP-IR01 PU Blend Polyols for PIR Panel
Introduction
VP-IR01 Blend Polyols is the pale yellow and brown
transparent liquid . It mixs isocyanate reacts to be
foam with good flame retardant performance,good
insulation effect, Pale quality, and higher compressive
strength. Widely used in the production of pir panel,
suitable for low pressure machine and high pressure
machine.
Product Parameters
1.Typical Physical Index
Appearance | Pale Yellow and Brown Transparent Liquid |
Hydroxyl Value , mgKOH/g | 200-280 |
Dynamic Viscosity at 25ºC , mPa.s | 150-250 |
Density at 20ºC , g/ml | 1.12-1.16 |
Storage Temperature , ºC | 10-25 |
Shelf Lift | 6 Months at Temperatures of 20-30°C |
2.Processing Condition Characteristics
Item | Manual Mixing | High Pressure Machine |
Mixing Ratio (PBW) | VP-IR01 : MDI =100: 150-160 | |
Components Temperature , ºC | 25 | 25 |
Mould Temperature , ºC | 50-60 | 50-60 |
Cream Time , s | 8-12 | 6-10 |
Gel Time , s | 40-60 | 35-50 |
Free Density , kg/m3 | 30-35 | 30-35 |
The actual data at customer site may be different because of test machine and condition etc. |
3.Foam Property
Item | Index | |
Moulding Density | ≥45kg/m3 | |
Closed-Cell Rate | ≥90% | |
Initial Thermal Conductivity at 15ºC | ≤0.025 W/m.K | |
Compressive Strength (Perpendicular to the Direction of Rising) | ≥200BMPa | |
Dimensional Stability | 24h at -30ºC | ≤0.5% |
24h at 100ºC | ≤0.5% | |
Fireproof Grade | B2 | |
Water Absorption | ≤3% |
Packaging & Shipping
Packing: 220kgs/Net Steel Drum,1000kgs/IBC Tank or ISO TANK
Stored & Shipping:
----To be kept in a cool well-ventilated place.
----To be Kept containers tightly closed , check regularly for
leaks.
----and Incompatibility with other
-----To be Stored away from oxidizing agent
![]() |
