Cooling System Injection Mold Chiller For Plastic Packaging
Injection Mold Chiller Information
An injection mold chiller is a cooling system specifically designed to regulate and maintain the temperature of injection molds used in plastic injection molding processes.
Injection mold chillers are crucial components in the plastic injection molding process, helping to maintain temperature stability, improve part quality, and enhance overall production efficiency.
Functionality:
Injection mold chillers are essential for maintaining consistent temperatures within the injection molds during the plastic injection molding process.
Temperature Control:
These chillers help to achieve precise temperature control, ensuring that the molten plastic material solidifies properly within the mold cavity.
Cooling System:
Injection mold chillers use a cooling system, typically involving a refrigeration unit or a water cooling system, to remove excess heat from the mold.
Injection Mold Chiller Details
| Description | ||
| Specifications: Chiller | ||
| Dimensions(H×W×D) | 1017×490×850mm | |
| P1 Chilled Water Inlet | 1inch | |
| P2 Chilled Water Outlet | 1inch | |
| P3 Water Tank Outlet Port | 1/2inch | |
| P4 Water Tank Overflow Port | 1/2inch | |
| P5 Cooling Water Outlet | 11/2inch | |
| P6 Cooling Water Inlet | 11/2inch | |
| Weight | 240kg | |
| Refrigerant Capacity | 10kW | |
| Compressor | Type | Scroll |
| Input Power | 3.3kW,5HP | |
| Refrigerant | Filling Volume | 3.1kg |
| Control Mode | Capillary | |
| Type | R410A | |
| Evaporator Type | Tube Style | |
| Condenser | Type | Tube-in-shell Style |
| Inlet/Outlet Pipe | 1.5inch | |
| Cooling Water Flow | 65L/min | |
| Water Tank Capacity | 55L | |
| Water Pump(50Hz) | Power | 0.37kW |
| Pump Flow | 60L/min | |
| Working Pressure | 2.0Bar | |
| Total Power | 3.67kW | |
| Pipe Coupling | Chilled Water Outlet | 1inch |
| Chilled Water Inlet | 1inch | |
| Water Tank Drainage Port | 1/2inch | |
| Water Tank Overflow Port | 1/2inch | |
| Protective Devices | Compressor | Built-in protective switch/Overload relay |
| Pump | Over Relay | |
| Refrigerant Loop | High/Low Pressure controller | |
| Power | 3Φ,400VAC,50Hz | |
| Measures Exchange | 1kW=860Kcal/hr | |
| 1RT=3,024Kcal/hr | ||
| 10,000Btu/hr=2,520Kcal/hr | ||
