Place of Origin: | China |
Brand Name: | GC |
Certification: | ISO |
MOQ: | 1 Set |
Packaging Details: | Wooden package |
Delivery Time: | In stock |
Payment Terms: | TT |
Supply Ability: | 100 Sets |
Price: | Negotiated |
Model Number: | GC-JZL-5D |
Model NO.: | GC-JZL-5D |
Transport Package: | Wooden Box Packaging |
Specification: | 85KG |
Trademark: | GC |
Origin: | Guangdong |
Customization: | Available |
After-sales Service: | Online Guidance |
Warranty: | 1 Year |
Company Info. |
Guangdong Guangce Instrument Technology Co., Ltd |
Verified Supplier |
View Contact Details |
Product List |
Digital Charpy Impact Test Machine
Model: GC-JZL
1. Product Introduction
The digital display simply supported beam impact tester is mainly
used for the determination of the impact toughness of non-metallic
materials such as hard plastics, reinforced nylon, glass fiber
reinforced plastics, ceramics, cast stones, and electrical
insulating materials. It is an ideal test equipment for chemical
industry, scientific institutions, colleges and universities,
quality inspection and other departments.
2. Test Standards
ISO179-2000 Determination of Impact Strength of Plastic-Hard
Material Simply Supported Beams
GB/T1043-2008 Impact Test Method for Rigid Plastic Simply Supported
Beam
JB/T8762-1998 Plastic Simply Supported Beam Impact Testing Machine
GB/T18743-2002 The Impact Test Method of Simply Supported Beam of
Thermoplastic Pipe for Fluid Transport (applicable to pipe
fittings.)
3. Features
Use high-strength carbon fiber swing rod to improve the rigidity of
the material
4. Parameters
Item | Simple supported beam |
Model | GC-JZL-5D |
The pendulum energy | 1J,2J,4J,5J |
Display mode | Color touch screen |
Pendulum pre-evalution angle | 150ºC |
Impact velocity | 2.9m/s |
Pendulum center distance | 230mm |
Angel accuracy | 0.01° |
Energy accuracy | 0.01J |
Jaw support spacing | 40mm,60mm,70mm,95mm(customizable) |
Supporting blade fillet radius | R=1mm |
Impact angle | 30° |
Fillet radius of impact blade | R=2mm±0.5mm |
Output method | Printout |
Power | 220V50HZ |
![]() |
