High Temp Resistance Graphite Boat Pushing Continuous Sintering Furnace For Powder Metallurgy

Categories Continuous Furnace
Price: USD12,000-100,000/SET
Brand Name: Jingtan
Certification: CE
MOQ: 1 set
Delivery Time: 60 days
Packaging Details: wooden case
Place of Origin: China
Payment Terms: L/C/T/T
Supply Ability: 5pcs/month
place of origin: Hunan, China
type: Resistance Furnace
usage: metallurgy powder furnace
video outgoing-inspection: Provided
machinery test report: Provided
core components: PLC
brand name: OEM
voltage: 380V
weight (t): 2 T
power (kw): 120
warranty: 1 Year
key selling points: Flexible Manufacturing
Maximum Temperature(℃): 2800
Temperature Control Method: PID Auto control
Working Method: Push boat intermittent feeding
Condition: New
Marketing Type: Ordinary Product
Warranty of core components: 1 Year
Showroom Location: Egypt, United Kingdom, Italy, Germany, Saudi Arabia, Russia, Malaysia
Applicable Industries: Energy & Mining, Metallurgy powder
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

High Temp Resistance Graphite Boat Pushing Continuous Sintering Furnace For Powder Metallurgy

High temperature resistance graphite boat pushing continuous sintering furnace for powder metallurgy

Products Description
Graphite pushing boat furnace:
Graphite pushing furnace uses graphite plate bearing graphite material box, with a push rod box after box to push to the heating
area, in the atmosphere protection state of powder reduction, sintering of powder metallurgy products and other heat treatment.

Suitable for powder metallurgy processing and graphite material processing.


Model
JT-ZTL-10
JT-ZTL-20
JT-ZTL-30
Capacity(kg/d)
200
700
400
Maximum Temperature(℃)
2800
Temperature Control Method
PID Auto control
Protective Gas
Ar
Rated Power(kw)
120
220
180
Voltage(V)
3 phase 380
Temperature Measurement Method
Infrared measurement
Working Method
Push boat intermittent feeding
Boat size
Φ120*320mm
Φ200*420mm
Φ150*400mm
Cooling Mode
cooling by circulating water

Features:

1) Adopt new heating technology, high service temperature and long service life;
2) Long service life of furnace tube, continuous production 20-30 days without stop the furnace;
3) Continuous material in and out, good sealing performance, less gas consumption;
4) Adopt push-boat production mode, continuous production can be continuously furnace;
5) Automatic boat loading, pushing, discharging and reversing mechanism can be selected, with stable product quality and low labor intensity;
6) The length of furnace body can be increased or decreased according to the actual situation of users;
7) With remote control function, remote control, fault diagnosis and software upgrade;
8) Three-phase power supply, three-phase power balance, stable performance.

Features 1:

1)Adopt new heating technology, high service temperature and long service life;
2)Long service life of furnace tube, continuous production 20-30 days without stop the furnace;
3) Continuous material in and out, good sealing performance, less gas consumption;
4) Adopt push-boat production mode, continuous production can be continuously furnace;

Features 2:

5) Automatic boat loading, pushing, discharging and reversing mechanism can be selected, with stable product quality and low labor intensity;
6) The length of furnace body can be increased or decreased according to the actual situation of users;
7)With remote control function, remote control, fault diagnosis and software upgrade;
8) Three-phase power supply, three-phase power balance, stable performance.
