Categories | Voltage Controlled Oscillator |
---|---|
Place of Origin: | Jiangsu, China |
Brand Name: | RFint |
Model Number: | YSGMTC5200 |
Price: | Prices are negotiable |
Packaging Details: | Opp bag |
Delivery Time: | 2-10days |
Specification: | Standard |
Packaging Type: | opp bag |
Application: | 4950MHz-5550MHz |
Package / Case: | Standard |
Series: | VCO |
Features: | High output power |
Size / Dimension: | 7mm*9mm*2mm |
Description: | Voltage Controlled Oscillator |
Manufacturing Date Code: | Other |
Frequency: | 4950~5550MHz |
Output power: | ≥ 6dBm @ VCC=5V |
Supply voltage: | 3V~6V |
Working current: | 14mA |
Company Info. |
Zhongshi Zhihui Technology (suzhou) Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
YSGMTC5200 is a highly integrated, standard package size VCO, which uses a high cut-off frequency RF transistor to generate oscillation and signal output. Its signal output power is high and its isolation is good.
The temperature compensation device is added to improve the temperature stability of the signal. It is supplied by 5V standard voltage and is compatible with the working voltage in the range of 3V to 6V.Nominal tuning frequency band | 4950~5550MHz@VT=0V ~ 5V |
Output power | ≥6dBm @VCC=5V |
In-band flatness (BW≤200MHz) | ±0.5dB |
Power supply voltage (VCC) | 3V ~ 6V |
Working current | 14mA |
Second harmonic suppression | ≤-25dBc |
Third harmonic suppression | ≤-25dBc |
Radio-frequency output impedance | 50Ω |
Universal package size | 7mm x 9mm x 2mm |
Packing & Delivery
Always final Inspection before shipment;
1 year warranty for our products.
![]() |
