| Categories | Stainless Steel Seamless Pipes |
|---|---|
| Brand Name: | YUHAO |
| Model Number: | Seamless Pipes |
| Certification: | ISO PED CE TUV |
| Place of Origin: | CHINA |
| MOQ: | 100KGS |
| Price: | NEGOTIATION |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000TONS/PER MONTH |
| Delivery Time: | 15-40DAYS |
| Packaging Details: | PACKAGED IN SEA-WORTH BUNDLES,PACKAGED IN PLYWOOD CASES |
| Steel grade: | 304, 316, 321, 310S, Duplex |
| Corrosion Resistance: | High-Temperature Oxidation Resistance, Seawater Resistance |
| Standard: | AISI, ASTM, DIN, EN, GB |
| OD: | 1/8" NB TO 32" NB , (10.29MM-812.80MM) |
| WT: | SCH 10S, SCH 40S, SCH 80S, SCH160, 0.5 mm to 50 mm |
| Length: | 0.5M-15M OR AS REQUESTED |
| Applications: | Mining, Shipbuilding, Construction, Pulp & Paper, Food, Medical Technology, Environmental Protection |
| Performance Testing: | Non-Destructive Testing, Pressure Testing, Mechanical Properties Testing |
| Package: | PACKAGED IN SEA-WORTH BUNDLES OR PLYWOODE CASE OR AS REQUESTED |
| Company Info. |
| Zhejiang Yuhao Stainless Steel Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
ASTM A312 TP316L Stainless Steel Seamless Pipe ABS DNV LR BV GL ASME
►Products Information
Stainless steel seamless pipes are high-performance, corrosion-resistant tubes widely used in industries such as oil and gas, chemical processing, and power generation. Manufactured through a precise extrusion or piercing process, these pipes lack welded seams, ensuring superior strength and durability. Their smooth internal surface minimizes friction, enhancing fluid flow efficiency. Available in various grades like 304, 316, and 321, they offer excellent resistance to high temperatures, pressure, and corrosive environments. Ideal for critical applications, stainless steel seamless pipes are valued for their reliability, longevity, and ability to maintain structural integrity under extreme conditions. They are a preferred choice for demanding industrial and commercial projects.
►Product Size
| STAINLESS STEEL (ASTM/ANSI) | ||||||||||
| B | O.D | SCH 5S | SCH 10S | SCH 10 | SCH 20S | SCH 40S | SCH 40 | STD | SCH 80S | SCH 80 |
| 1/8" | 10.29 | - | 1.24 | 1.24 | - | 1.73 | 1.73 | 1.73 | 2.41 | 2.41 |
| 1/4" | 13.72 | - | 1.65 | 1.65 | - | 2.24 | 2.24 | 2.24 | 3.02 | 3.02 |
| 3/8" | 17.15 | - | 1.65 | 1.65 | - | 2.31 | 2.31 | 2.31 | 3.2 | 3.2 |
| 1/2" | 21.34 | 1.65 | 2.11 | 2.11 | - | 2.77 | 2.77 | 2.77 | 3.73 | 3.73 |
| 3/4" | 26.67 | 1.65 | 2.11 | 2.11 | - | 2.87 | 2.87 | 2.87 | 3.91 | 3.91 |
| 1" | 33.4 | 1.65 | 2.77 | 2.77 | - | 3.38 | 3.38 | 3.38 | 4.55 | 4.55 |
| 1 1/4" | 42.16 | 1.65 | 2.77 | 2.77 | - | 3.56 | 3.56 | 3.56 | 4.85 | 4.85 |
| 1 1/2" | 48.26 | 1.65 | 2.77 | 2.77 | - | 3.68 | 3.68 | 3.68 | 5.08 | 5.08 |
| 2" | 60.33 | 1.65 | 2.77 | 2.77 | - | 3.91 | 3.91 | 3.91 | 5.54 | 5.54 |
| 2 1/2" | 73.03 | 2.11 | 3.05 | 3.05 | - | 5.16 | 5.16 | 5.16 | 7.01 | 7.01 |
| 3" | 88.9 | 2.11 | 3.05 | 3.05 | - | 5.49 | 5.49 | 5.49 | 7.62 | 7.62 |
| 3 1/2" | 101.6 | 2.11 | 3.05 | 3.05 | - | 5.74 | 5.74 | 5.74 | 8.08 | 8.08 |
| 4" | 114.3 | 2.11 | 3.05 | 3.05 | - | 6.02 | 6.02 | 6.02 | 8.56 | 8.56 |
| 5" | 141.3 | 2.77 | 3.4 | 3.4 | - | 6.55 | 6.55 | 6.55 | 9.53 | 9.53 |
| 6" | 168.28 | 2.77 | 3.4 | 3.4 | - | 7.11 | 7.11 | 7.11 | 10.97 | 10.97 |
| 8" | 219.08 | 2.77 | 3.76 | 3.76 | 6.35 | 8.18 | 8.18 | 8.18 | 12.7 | 12.7 |
| 10" | 273.05 | 3.4 | 4.19 | 4.19 | 6.35 | 9.27 | 9.27 | 9.27 | 12.7 | 15.09 |
| 12" | 323.85 | 3.96 | 4.57 | 4.57 | 6.35 | 9.52 | 10.31 | 9.52 | 12.7 | 17.48 |
| 14" | 355.6 | 3.96 | 4.78 | 6.35 | 7.92 | - | 11.13 | 9.52 | - | 19.05 |
| 16" | 406.4 | 4.19 | 4.78 | 6.35 | 7.92 | - | 12.7 | 9.52 | - | 21.44 |
| 18" | 457.2 | 4.19 | 4.78 | 6.35 | 7.92 | - | 14.27 | 9.52 | - | 23.83 |
| 20" | 508 | 4.78 | 5.54 | 6.35 | 9.52 | - | 15.09 | 9.52 | - | 26.19 |
| 22" | 558.8 | 4.78 | 5.54 | 6.35 | 9.52 | - | 15.09 | 9.52 | - | 28.58 |
| 24" | 609.6 | 5.54 | 6.35 | 6.35 | 9.52 | - | 17.48 | 9.52 | - | 30.96 |
| 26" | 660.4 | - | 7.92 | 12.7 | - | 17.48 | 9.52 | - | ||
