| Categories | ABB TZID Valve Positioner |
|---|---|
| Brand Name: | ABB |
| Model Number: | ACH580-04-650A-4 |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1pc |
| Price: | negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100pcs per month |
| Delivery Time: | 3-5 weeks |
| Packaging Details: | Original packaging |
| Enclosure Type NEMA: | Open Type |
| Altitude: | 1000 m |
| Operating Humidity (RHamb): | 95 |
| Sound dB (A): | 72 dB(A) |
| Frame Size: | R10 |
| Input Voltage (Uin): | 380 ... 480 V |
| Company Info. |
| SC Automation Limited |
| Verified Supplier |
| View Contact Details |
| Product List |
ACH580 HVAC drive offering has all key features built-in to control fans, pumps and compressors, and more complex equipment like air-handling units and chillers, ensuring smooth, energy-efficient operation of your HVAC systems in normal and mission-critical situations. The built-in features significantly reduce installation time, and the intuitive control panel with an HVAC-specific primary settings menu and help assistants makes startup, commissioning and operation easy. The optional Bluetooth® capability enables the commissioning and monitoring of the drive from a distance. The ACH580-04 drive module comes in IP00 enclosure as standard for cabinet installation. Also, IP20 enclosure is available.
| Number of Phases | 3 |
| Degree of Protection | IP00 |
| Enclosure Type NEMA | Open Type |
| Altitude | 1000 m |
| Operating Humidity (RHamb) | 95 |
| Sound dB (A) | Sound dB (A) |
| Multiple Battery Information | Lithium Coin, CR2032, 220 mAh, 3 V, 1 pc, 3 g |
| Frequency (f) | 47.5 ... 63 Hz |
| Frame Size | R10 |
| Input Voltage (Uin) | 380 ... 480 V |
| Mounting Type | Module |
| Communication Protocol | BACNET CAN DeviceNet EtherNet/IP LON MODBUS Other Bus Systems PROFIBUS PROFINET IO TCP/IP |
| Number of Hardware Interfaces | Industrial Ethernet 0 Other 2 Parallel 2 PROFINET 0 RS-232 0 RS-422 0 RS-485 1 Serial TTY 0 USB 1 |
| Includes | Control unit PC connection |
| Analog Inputs | 2 |
| Analog Outputs | 2 |
| Number of Digital In/Outputs | 6 / 3 |
| Output Current, Normal Use (In) | 650 A |
| Output Current, Light-Overload Use (ILD) | 634 A |
| Output Current, Heavy-Duty Use (IHD) | 477 A |
| Output Power, Normal Use (Pn) | 355 kW |
| Output Power, Light-Overload Use (PLD) | 355 kW |
| Output Power, Heavy-Duty Use (PHD) | 250 kW |
| Power Consumption (@Pcons) | 8046 W |
| Apparent Power Output | 450 kV·A |
| Efficiency Level | IE2 |
| Standby Loss | 423 W |
|
