| Categories | Regenerative Catalytic Oxidation |
|---|---|
| Certification: | CE |
| Brand Name: | CHG |
| Model Number: | WTE-01 |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 sets per year |
| Delivery Time: | Varies depending on the design |
| Packaging Details: | Varies depending on the design |
| Control Unit: | PLC |
| Mini Order Qty: | 1 Set |
| Package Size: | 570.00cm * 283.00cm * 190.00cm |
| Package Gross Weight: | 2650.000kg |
| After-sales Service: | Guide Equipment Installation and Use |
| Shipping Cost: | Contact the supplier about freight and estimated delivery time. |
| Company Info. |
| CHG International Limited |
| Verified Supplier |
| View Contact Details |
| Product List |
Key Features of the System:
Fully Automated Process
The entire system achieves automated purification and desorption, ensuring no secondary pollution during operation.
Two-Stage Dust Filtration
A dual-stage pre-filtration system is installed before the adsorption bed, enhancing purification efficiency and extending the adsorption device’s service life.
High-Performance Adsorption Material
Utilizes specially molded honeycomb activated carbon or zeolite molecular sieves with 8–10 times the density of conventional fiber adsorbents.
Capable of adsorbing organic solvents up to 25% of its total weight before regeneration.
Benefits: Long service life, low system resistance, and high purification efficiency.
Advanced Catalytic Combustion
Precious metal catalysts (palladium & platinum) on honeycomb ceramics ensure:
Low resistance, high activity, and long lifespan
Low decomposition temperature & short desorption preheating time
Energy-efficient operation with excellent stability
Maintains self-sustained combustion at 2000ppm organic waste gas concentration.
Catalytic combustion efficiency exceeds 97% with high conversion rates and stable performance.
Waste Heat Recovery for Energy Savings
Hot air (from catalytic combustion waste heat) serves as the desorption medium.
Concentrated organic waste gas is fed back into the catalytic burner for purification, eliminating additional energy needs and significantly reducing operating costs.
PLC Automated Control System
Ensures safe, stable, and reliable operation with full automation, including:
Automatic catalytic combustion heating
Program-controlled desorption process
Real-time temperature feedback for precise desorption control
|
