4.2'' E Paper Display With 400x300 Pixel For Price Label Display E Book

4.2 Inch E-Paper Display With 400x300 Pixel For Price Label Display E Book

Over View

DEPT0420RWS830F17 is an Active Matrix Electrophoretic Display (AM EPD), with interface and a reference system design. The display is capable to display images at 1-bit white, black and red full display capabilities. The 4.2inch active area contains 300×400 pixels. The module is a TFT-array driving electrophoresis display, with integrated circuits including gate driver, source driver, MCU interface, timing controller, oscillator, DC-DC, SRAM, LUT, VCOM. Module can be used in portable electronic devices, such as Electronic Shelf Label (ESL) System.

Features

◆300×400 pixels display

◆High contrast High reflectance

◆Ultra wide viewing angle Ultra low power consumption

◆Pure reflective mode

◆Bi-stable display

◆Commercial temperature range

◆Landscape portrait modes

◆Hard-coat antiglare display surface

◆Ultra Low current deep sleep mode

◆On chip display RAM

◆Waveform can stored in On-chip OTP or written by MCU

◆Serial peripheral interface available

◆On-chip oscillator

◆On-chip booster and regulator control for generating VCOM, Gate and Source driving voltage

◆I 2 C signal master interface to read external temperature sensor

◆Built-in temperature sensor

BS1 State MCU Interface

L 4-lines serial peripheral interface(SPI) - 8 bits SPI

H 3- lines serial peripheral interface(SPI) - 9 bits SPI
