Categories | TFT LCD Display |
---|---|
Brand Name: | ESEN |
Model Number: | T035SHV40E3014 |
Certification: | ISO9001/ISO14001 |
Place of Origin: | Shenzhen China |
MOQ: | 1000/PCS |
Price: | Please enquiry |
Payment Terms: | L/C,T/T |
Supply Ability: | 300K/mth |
Delivery Time: | 2-4 weeks |
Packaging Details: | All products are packaged in an appropriate and correct manner. |
LCD Size: | 3.5inch |
Driver IC: | IL9488 |
Resolution: | 320(horizontal)*480(Vertical) |
Operating temp: | -20°C~+70°C |
Storage temp: | -30°c~+80°c |
Backlight: | WHITE(3.2V120mA) |
Operating Voltage:: | VDD=2.8V |
Interface: | RGB interface |
Cnnect type: | connector |
Color Depth: | 262K |
Technology type: | a-Si |
Display Spec. Pixel pitch (mm): | 0.153x 0.153 |
Piel Configuration: | R.G.B. Vertical Stripe |
Display Mode: | Normally White |
Surface Treatment: | HC |
Viewing Direction: | 6 O'cock |
LCM(WxHxD)(mm): | 54.48*84.71*2.30 |
Active Area(mm): | 48.96 x 73.44 |
With /without TSP: | Without TSP |
LED Numbers: | 6 LEDS |
Company Info. |
ESEN HK LIMITED |
Verified Supplier |
View Contact Details |
Product List |
Product Description
This Industrial Touch Screen is a color-active matrix thin-film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. If your product requires a size 3.5 inch then our lcd is just what you need. Improve your product design by adding our 320(horizontal)*480(Vertical) resolution product.
Q: I cannot find the size, the interface or the FPC I need, is it
possible for customization?
A: Of course you can customize. Just tell us what you need.
However, TFT LCD module has different tooling cost which includes
FPC, Touch screen, backlight, bezel and so on.
Q: Can I pay the order with credit cards or PayPal?
A: We accept PayPal and credit card for sample, T/T paid for mass
order. We also accept advanced percentage (usually 30% before
producing) for large orders.
Q: How long can I get the goods?
A: It depends on the quantity. Our inventory is mainly raw
materials, semi-finished and a small number of finished products.
Samples available in stock will be sent in 3 days; Small batch
delivery takes 15-20 working days include producing; Large batch
delivery takes 20-30 working days. We will list the time cost for
you before order.
Q: What kind of packaging? Will the transport process be damaged?
A: Packed in anti-static bags with foam box to ensure safety in
transportation.
