| Categories | VA LCD Display |
|---|---|
| Brand Name: | Genyu |
| Model Number: | GY64787A-0GPNS-02 |
| Certification: | RoHS, ISO9001:2015 |
| Place of Origin: | China |
| MOQ: | 750 pieces |
| Price: | Negotiation |
| Payment Terms: | T/T, Paypal, Western Union, MoneyGram, Credit Card |
| Supply Ability: | 500K pcs/ Month |
| Delivery Time: | 38-40 days |
| Packaging Details: | Foam & Cartons |
| LCD Type: | VA, nagative |
| Viewing Angle: | 12 O'clock |
| Operating Temperature: | -20~+70℃ |
| Voltage: | 3.3V |
| Connector: | PIN |
| Company Info. |
| Shenzhen Genyu Optical Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
A VA negative LCD is a high-contrast display using Vertical Alignment (VA) liquid crystal technology in negative mode, meaning:
The background appears black
The segments (text/icons) are light-colored, typically white, blue, or amber
This combination results in a sleek, high-end, and visually striking display, often used in premium devices.
Key Features of VA Negative LCDs:
| Feature | Description |
|---|---|
| Display Mode | Negative |
| Background | Deep black (thanks to VA technology) |
| Segment Color | White, blue, amber, green, etc. (lit by backlight) |
| Contrast Ratio | High (500:1 to 1000:1) |
| Viewing Angle | Wide (up to 160°) |
| Backlight | Required (commonly LED) |
| Power Consumption | Moderate (due to constant backlight) |
| Design Look | Clean, modern “black screen” when off |
Detailed Parameters:
| Model number | GY64787A-0GPNS-02 | LCD type | Segmented Display |
| Module size | 113.0(W)* 75.2(H)* 2.8(T) mm | Display mode | VA, Negative |
| LCD viewing area | 110.0(W)* 68.2(H) mm | Polarizer type | Transmissive |
| Operating Temperature | -20~+70℃ | LED backlight | White |
| Drive method | 1/4 Duty, 1/3 Bias | Working voltage | 3.3V |
| Viewing angle | 12 O'clock | Connection way | PIN, 78 numbers |
Why Choose a VA Negative LCD?
Black panel when off – Looks like glass, blends with modern UI
High brightness and contrast – Readable in almost all conditions
Great viewing angle – Perfect for angled or wall-mounted devices
Colored segments – Blue or white on black offer strong visual appeal
1. Q: What products can you provide?
A. 1) Custom Segment LCD Display;
2) Monochrome Graphic/Dot Matrix LCD Display Modules;
3) Micro OLED Display Modules;
4) Color TFT LCD Display Panels;
5) LED Backlights.
2. Q: What is the process for custom samples?
A: Send inquiry -- Offer quotation -- Confirm quotation & Pay tooling charge -- Provide drawing -- Confirm drawing -- Make tooling & samples -- Samples finished -- Delivery via freight or sea collect.
3. Q: How long can I get the custom samples?
A: Different product types will take different times. Usually, it will take about 30-35 days.
4. Q: Can I get free samples?
A: We would like to provide 3-10 pieces of free samples after tooling.
5. Q: What is the minimum order quantity?
A: MOQ mainly depends on LCD sizes.
6. Q: How long is it for mass production?
A: Usually 35-45 days, it depends on your part number.
7. Q: How do you control the quality of products?
A: All products are 100% inspected before shipment.
|
