| Categories | VA LCD Display |
|---|---|
| Brand Name: | Genyu |
| Model Number: | GY88128-1546-A1 |
| Certification: | RoHS, ISO9001:2015 |
| Place of Origin: | China |
| MOQ: | 4900 pieces |
| Price: | Negotiation |
| Payment Terms: | T/T, Paypal, Western Union, MoneyGram, Credit Card |
| Supply Ability: | 300K pcs/ Month |
| Delivery Time: | 40-45 days |
| Packaging Details: | Anti-static bags & Cartons |
| LCD Type: | VA, negative |
| Viewing Angle: | 12 O'clock |
| Operating Temperature: | -20~+70℃ |
| Voltage: | 5.0V |
| Driver IC: | HT1621 |
| Connector: | PIN |
| Company Info. |
| Shenzhen Genyu Optical Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Overview and Key Information:
A VA (Vertical Alignment) LCD module is a pre-assembled display unit using VA technology, often including:
Glass panel (LCD)
Driver IC
PCB or FPC interface
Optional backlight
Sometimes a frame, bezel, or touch panel
VA LCD modules are used when high contrast, wide viewing angles, and a modern black-screen appearance are desired, but without the complexity and cost of full-color TFT displays.
Detailed Parameters:
| NO. | ITEM | SPECIFICATIONS |
| 1 | Model Number | GY88128-1546-A1 |
| 2 | LCD Type | VA negative, transmissive |
| 3 | Viewing Angle | 12 O'clock |
| 4 | Drive Method | 1/4 Duty, 1/3 Bias, 5.0V |
| 5 | Operating Temperature | -20~+70℃ |
| 6 | Storage Temperature | -30~+80℃ |
| 7 | Connector | COB+PIN |
| 8 | Driver IC | HT1621(SMT) |
| 9 | Backlight | LED, 2 PCS, white |
| 10 | Module Size | 67.01(W)* 40.23(H)* 16.5(T) mm |
| 11 | LCD View Area | 53.5(W)* 18.9(H) mm |
Common Applications of VA LCD Modules:
Smart home devices (thermostats, scales)
Medical instruments (ECGs, monitors)
Car infotainment or HVAC panels
High-end appliances (ovens, air purifiers)
Industrial control panels
Customization Options:
You can often customize the following:
Segment shapes and icons
Display colors (segment and backlight)
Viewing angle orientation (6 o’clock, 12 o’clock, etc.)
Touch panel integration
Outer frame/housing dimensions
1. Q: What products can you provide?
A. 1) Custom Segment LCD Display;
2) Monochrome Graphic/Dot Matrix LCD Display Modules;
3) Micro OLED Display Modules;
4) Color TFT LCD Display Panels;
5) LED Backlights.
2. Q: What is the process for custom samples?
A: Send inquiry -- Offer quotation -- Confirm quotation & Pay tooling charge -- Provide drawing -- Confirm drawing -- Make tooling & samples -- Samples finished -- Delivery via freight or sea collect.
3. Q: How long can I get the custom samples?
A: Different product types will take different times. Usually, it will take about 30-35 days.
4. Q: Can I get free samples?
A: We would like to provide 3-5 pcs free samples after tooling.
5. Q: What is the minimum order quantity?
A: MOQ mainly depends on LCD sizes.
6. Q: How long is it for mass production?
A: Usually 35-45 days, it depends on your part number.
7. Q: How do you control the quality of products?
A: All products are 100% inspected before shipment.
|
