| Categories | Copper Nickel Alloy |
|---|---|
| Brand Name: | HUONA |
| Model Number: | CuNi44 |
| Place of Origin: | CHINA |
| MOQ: | 100 Meters |
| Price: | US$20.00 |
| Payment Terms: | T/T,Western Union,MoneyGram,L/C |
| Supply Ability: | 500 Tons Per Month |
| Delivery Time: | 5-21DAYS |
| Packaging Details: | Spool Package With Carton Box, Coil Package With Polybag For Cuni44 |
| Material:: | Nickel Copper |
| Resistivity:: | 0.5 |
| Density:: | 8.9 G/cm3 |
| Condition:: | Hard / Soft |
| Melting Point:: | 1100℃ |
| Tensile Strength: | 420 MPA |
| Maximum Temperature:: | 420℃ |
| Sureface：: | Bright |
| Company Info. |
| Huona (Shanghai) New Material Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Copper Nickel/ CuNi44/Constantan Heating Wire / Wires
| Product Name | Copper Nickel Alloy CuNi Wire |
| Product Description | Copper Nickel Alloy is mainly made of copper and nickel. The copper and nickel can be melted together no matter what percentage. Normally the resistivity of CuNi alloy will be higher if the Nickel content is larger than Copper content. From CuNi6 to CuNi44, the resistivity is from 0.1μΩm to 0.49μΩm. That will help the resistor manufacture choosing the most suitable alloy wire. |
| Product Features | By the way, the Copper Nickel wire is easy to be welded and easy to be fabricated, so it can be made into many forms and widely used in all areas. |
Specification
| Wire | D=0.03mm~8mm |
| Ribbon | Width=0.4mm-40mm, Thickness=0.03mm-2.9mm |
| Strip | Width=8mm-250mm, Thickness=0.1mm-3mm |
| Foil | Width=6mm-120mm, Thickness=0.003mm-0.1mm |
| Bar | Width=8mm-100mm, Thickness=50mm-1000mm |
| Other sizes | Available Upon Your Requirements |
|
