IP65 Digital Speed Limit Signs , Electronic Speed Warning Signs Pitch 31.25mm

Categories Traffic LED Display
Brand Name: HANJING
Model Number: electronic speed limit sign
Certification: CE/ROHS/FCC/ETL/TUV
Place of Origin: ShenZhen,China
MOQ: 1pc/1sqm
Price: Negotiation
Payment Terms: 35% T/T as prepayment,65% T/T as balance at factory, Western Union, MoneyGram
Supply Ability: 1000 sets per month
Delivery Time: 8-25 working days after received your payment
Packaging Details: Plywood cartons or flight case packaging
Cabinet Size(WXH): size can be customized.
Brightness: ≤8000 nit
IP Grade: IP65
LED Type: DIPLED
Cabinet Material: Epoxy paint coated Cold rolled steel
Operating environment: -30℃-60℃;10%-90%RH
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

IP65 Digital Speed Limit Signs , Electronic Speed Warning Signs Pitch 31.25mm

Feature:

Pitch 31.25mm;
Pixel config: 2R1G1B / 1R1G1B;
Brightness:8000nit+;
Cabinet protection: IP65/65;
Front service;
Tri-color/ Full Color;
Remote control by Fiber optic or 4G;
Communication protocal:TCP/IP;


LED intelligent traffic screen mainly includes: traffic variable information signs, car information advertising screen, etc. The traffic variable information sign screen can be divided into variable information board, speed limit sign, traffic route display screen, lane indicator, fare screen and traffic signal light, etc

Traffic variable information sign is mainly used for road traffic information release, road traffic penetration, road speed limit and toll station lane traffic instructions, fee information and road traffic signals


Specifications:


ModuleTechnical Parameters
Pixel Pitch20mm
LED TypeDIP LED
Module Size (mm)size can be customized.
Module Resolutioncustom-made
Module weight45kg/ sq.m
Brightness≤8000 nit
Refresh Rate≥1920 Hz
Driving MethodStatic scan
Grey level16bits
Color Display281 trillion
IP GradeIP65
Power consumption (Max/ biggest)700 W/sq.m
Power consumption (Max/Average)240 W/sq.m
LifeSpan100000 hour
Cabinet
Cabinet Size(WXH)size can be customized.
Cabinet resolutionsize can be customized.
Cabinet MaterialIron box technology
Cabinet weight(kg)455kg/m²
Pixel density1600Pixeles /m²
InstallationFlat Installation And Arc Installation
Control systemFull color asynchronous /synchronous
Data interconnectionUTP Cat 5
SoftwarePC software or Android App or IOS App
Mounting systemFixed with M10 bolts
Application environment
Input AC power voltage110V-240V
Working temperatureoudoor:-30℃~60℃
Working humidityhumidity:10%-90%RH
Signal type(with video processor)TCP / IP
Control distanceHSYV: <100m; SMF: <10km
