| Categories | Coal Fired Steam Boiler |
|---|---|
| Brand Name: | YONGXING |
| Model Number: | DZL/DZH |
| Certification: | CE/ISO/ASME |
| Place of Origin: | CHINA |
| MOQ: | 1ste |
| Price: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 1-1000 set |
| Delivery Time: | 20 days |
| Packaging Details: | nude packing/wooden packing |
| Product name: | Coal Fired Boilers, Industrial Travelling Grate Boiler |
| Fuel: | Coal-fired,biomass,straw,husk |
| Pressure: | High Pressure |
| Dimension(l*w*h): | Customization |
| Output: | Steam |
| Thermal efficiency: | >=80% |
| Material: | Q345R Steel Plate |
| Color: | Customization |
| Weight: | depends on capacity |
| After-sales service provided: | Engineers available to service machinery overseas |
| Company Info. |
| Yong Xing Boiler Group Co.,Ltd |
| View Contact Details |
| Product List |
Excellent Quality Industrial Travelling Grate Boiler and Coal Fired Boilers for Greenhouse Heating System
The travelling grate boiler is a horizontal three-return hybrid boiler in which a bundle of threaded tobacco pipes is arranged. A light pipe water cooling wall is installed on the left and right sides of the furnace. The movable grate is equipped with a blower and an induced draft fan for mechanical ventilation.
Features
1. Coal fired steam boiler adopts light chain belt grate, with high degree of automation,
equipped with dust removal equipment, less environmental pollution,
and has good comprehensive economic and technical indicators, which
are highly praised by enterprise users.
2. The travelling grate boiler are carefully designed according to the needs of various types of
enterprises. It has the advantages of quick installation, time
saving and material saving, compact structure and small floor
space.
3. The chain grate coal fired steam boiler produced by the company has high reliability, high thermal
efficiency and strong load capacity, and is an advantageous product
in its class.
4. The industrial biomass boiler body and base have been assembled in the factory. After the other
auxiliary machines of the user are in place, only the interfaces
and piping systems need to be connected, and the equipment can
operate normally.
5. The biomass fired steam boiler adopts a new curved arm screw adjustment structure. This structure
has the characteristics of flexible adjustment and uniform
distribution.
6. The travelling grate boiler adopts push-pull gate ash cleaning device. The gate is made of
heat-resistant cast iron, and the sealing effect is good,
effectively preventing the occurrence of combustion deformation and
grate leakage.
7. The wood fired boiler is heated surface processing using a fully automatic gas shielded welding process, and X-ray inspection of all solder joints. Ensure that the welding quality is stable and reliable.
DZL Travelling Grate Boiler Technical Data Sheet
| DZL Coal Fired Steam Boiler Technical Parameters | |||||
| Paraments | DZL1-A II | DZL2-A II | DZL 4-A II | DZL8-A II | |
| Rated evaporation capacity (T) | 1 | 2 | 4 | 8 | |
| Rated working pressure (MPa) | 0.7/1.0/1.25 | 0.7/1.0/1.25 | 1.25/1.6 | 1.25/1.6 | |
| Rated steam temperature (℃) | 170/184/194 | 170/184/194 | 194/204 | 194/204 | |
| Water-supply temperature(℃) | 20 | 20 | 20 | 20 | |
| Boiler heating area (㎡) | 57.47 | 89.4 | 124.9 | 432.22 | |
| Grate area (㎡) | 2.7 | 3.45 | 5.9 | 10.81 | |
| Exhaust flue gas temperature (℃) | 120.7 | 157 | 167 | 163.41 | |
| Thermal Efficiency (%) | 80.42 | 78.4 | 79.7 | 79.36 | |
| Size (m) | 5.27*2.5*3.15 | 5.4*2.4*3.48 | 6.18*2.95*3.35 | 9.05*3.2*4.3 | |
| Consumption (kg/h) | 155 | 306 | 611 | 1153 | |
| Induced Draft Fan | Model | Y9-19-6.3C | GY2-15 | Y6-41-7.1C | Y9-26-10D |
| Power(KW) | 5.5 | 11 | 18.5 | 45 | |
| Forced Draft Fan | Model | 4-72-3.3A | GG1-15 | G6-41-6.4A | 4-72-5A |
| Power(KW) | 2.2 | 3 | 5.5 | 15 | |
| Water Pump | Model | 1W2.4-10.5 | 11/2GC-5*7 | 11/2GC-5*7 | 2GC-5*6 |
| Power(KW) | 3 | 7.5 | 7.5 | 18.5 | |
| Grate Governor Box | Model | WT-4 | WT-5 | WT-6 | WT-10 |
| Power(KW) | 0.55 | 0.55 | 0.55 | 1.1 | |
| Slag Remover | Model | GBC-1 | GBC-2 | GBC-4 | GBC-8 |
| Power(KW) | 1.1 | 1.1 | 1.1 | 1.5 | |
| Coal Conveyor | Model | FS-1 | FS-2 | FS-4 | FS-8 |
| Power(KW) | 1.1 | 1.1 | 1.1 | 1.5 | |
DZH Biomass Steam Boiler Technical Data Sheet
| Parameters Table for DZH 0.5-6 ton | ||||||||
| Item No. | DZH0.5-0.7 | DZH1-1.0 | DZH1-1.25 | DZH2-1.0 | DZH2-1.25 | DZH4-1.25 | DZH4-1.6 | DZH6-1.25 |
| Rated steam output(t/h) | 0.5 | 1 | 1 | 2 | 2 | 4 | 4 | 6 |
| Rated work pressure(Mpa) | 0.7 | 1 | 1.25 | 1 | 1.25 | 1.25 | 1.6 | 1.25 |
| Rated steam temperature(°C) | 165.3 | 184 | 194 | 184 | 194 | 194 | 204 | 194 |
| Rated feed water temperature(°C) | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Thermal efficiency(%) | 76.6 | 77.18 | 77.6 | 76.8 | 77.7 | 78.8 | 78.8 | 78.5 |
| Fuel consumption (kg/h) | 79 | 172 | 178 | 358 | 361 | 726 | 732 | 1080 |
| Shipping size(m) | 3.67* 1.76* 2.78 | 4.31* 1.9* 2.86 | 4.31 *1.9* 2.85 | 5.41 *2.6* 3.1 | 5.41 *2.6* 3.26 | 5.86 *2.8* 3.39 | 5.86 *2.8* 3.4 | 6.2* 2.96* 3.58 |
|
