Waterproof 24AWG Cat5e Utp Network Cable High Speed ETL UL Approved

Categories Cat5e UTP Cable
Brand Name: YYS
Model Number: CAT5E UTP PLENUM
Certification: ETL UL CPR
Place of Origin: CHINA
MOQ: 10KF
Packaging Details: 305M/PULL BOX, 500FT/BOX
CAT5E: Solid bare copper 0.5mm
Flame retarded: CMP
Approved: ETL UL
Pull out: Smooth, Without Kink
Coil: Without Coiled Back
Performance: Stable
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Waterproof 24AWG Cat5e Utp Network Cable High Speed ETL UL Approved

24AWG CAT5E U/UTP Plenum CMP ,Solid Bare Copper,Without Kink 100% Pass Fluke Test 1800


Application:


- 10/100 Base - T4
- 100 Base - TX
- 155Mbps ATM
- 622Mbps ATM


Conductor

Material: Bare Copper

Nom O.D (mm); 0.5mm (+/-0.005mm)

Insulations: FEP

0.86+/-0.03mm


Sheath Physical

Properties

Before Aging Tensile Strength (Mpa) ≥10.0

Elongation(%) ≥100

Aging Period (℃×hrs) 100℃×24h×7d
After Aging Elongation(%) ≥75

Cold bend(-20±2℃×4h)

8×Cable O.D., No visible cracks

Electrical

Characteristics

(20℃)

Capacitance Unbalance (pF/100m) ≦330
DC Conductor Resistance Unbalance (%) max 5.0
DC Resistance (Ω/1Km) max 98

Impedance ((Ω) 1.0-100.0MHz 100±15

100.0-350.0MHz 100±20

DC Resistance (Ω/1Km) max NVP : 70%

--------

Dielectric Test 2kv/min
Temperature Range:-20℃ to + 75℃

Technical Performance (100m):

Frequency RL   ATT NEXT PHASE DELAY

(MHz) ≥dB    ≤dB    ≥dB ≤ns

1 20.0 2.0 65.3 570.0

4.0 23.0 4.1 56.3 552.0

8.0 24.5 5.8 51.8 546.7

10.0 25.0 6.5 50.3 545.4

16.0 25.0 8.2 47.3 543.0

20.0 25.0 9.3 45.8 542.1

25.0 24.3 10.4 44.3 541.2

31.25 23.6 10.7 42.9 540.4

62.5 21.5 17.0 38.4 538.6

100 20.1 19.8 35.3 537.6

200 18 29.0 30.8 536.5

350 16.3 44.9 27.2 535


Frequency PSNEXT ELFEXT PSELFEXT

(MHz) ≥dB ≥dB ≥dB

1 62.3 63.8 60.8

4 53.3 51.7 48.7

8 48.8 45.7 42.7

10 47.3 43.8 40.8

16 44.2 39.7 36.7

20 42.8 37.7 34.7

25 41.3 35.8 32.8

31.25 39.9 33.9 30.9

62.5 35.4 27.8 24.8

100 32.3 23.8 20.8

200 27.8 17.7 14.7

350 26.3 12.9 9.9


FAQ
1. Q: What kind of cable do you produce?
We specialize in producing all kinds of LAN cable,Speaker cable, Security Cable Especially CAT5E,Cat6, Cat6A UTP/ S/FTP, CMP
2.what's your MOQ?

A: Our MOQ is 10 pieces per item. Free samples can be sent for your quality evaluation.


3. Q: What’s your delivery time?
Normally, our delivery time is 7-15 days after receiving deposit. Base on the quantity of the order.


4. Q: What are your payment terms?
We accept T/T, L/C. Western Union,Other payments accept through negotiation.


5. Q: What is your manner of packing?

The color box , cartons and Wooden Drum


6. Q: Can your factory customize cables based on customer’s samples?

Yes, we can. OEM is welcomed.
