Fully Auto Aluminum Side Plate Radiator Making Machine for Brazing Radiators

Categories Radiator Making Machine
Place of Origin: Jiangsu, China (Mainland)
Brand Name: WONDERY
Supply Ability: 100 Set/Sets per Year
Packaging Details: plywood case suitable for sea transportation
MOQ: 1 Set
Price: Negotiable
Model Number: BBJ
Certification: CE
Delivery Time: 90 Days
machine name: Radiator making machine
aluminum strip width: 22-80mm
power: 24kw
overall size: 7500*1200*2200mm
aluminum coil: 1 coil a time
side plate edge folding: 8-10mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Fully Auto Aluminum Side Plate Radiator Making Machine for Brazing Radiators

Fully Auto Aluminum Side Plate Radiator Making Machine for Brazing Radiators


1. Application

The side plate radiator making machine is used to make the side plate automatically from the aluminum strip

through the procedures of straightening, hole punching, bending, end forming and cutting.


2. Main Technical Parameters

2.1 aluminum strip coil size: ID Ф400~Ф500mm; OD: max Ф1100mm;

2.2 aluminum strip width: 22-80mm;

2.3 length range: 200-1200mm;

2.4 feeding speed: 20m/min;

2.5 aluminum strip coil loaded per time: 1 coil;

2.6 processing speed: 3-4 side plates per min (length at 600mm );

2.7 edge folding height: 8-10mm;

2.8 equipment punching force: about 5T for work position 1,2, and 4; about 30T for work position 3;

2.9 power supply: AC380V 50Hz

2.10 equipment power: about 24.0kw

2.11 equipment size: 7500*1200*2200mm

2.12 equipment weight: about 10T


3. Components List of Side Plate Radiator Making Machine

Main Components


ItemBrand
PLCSiemens
Servo motor and servo magnifierSiemens
Touch screenSiemens
Intermediate relaySchneider
Proximity switchOmron
Circuit breakerSchneider
ContactorSchneider
Switch power supplySchneider
Linear rail and ball screwTBI
Solenoid valveAIRTAC
Pneumatic cylinderAIRTAC
Air and water separatorAIRTAC
Hydraulic systemDomestic brand

4. Company Info

Wuxi Wondery Trading Co., Ltd is a comprehensive fin radiator making machine supplier. Our company

supplies the following machines: aluminum radiator fin machine, aluminum radiator core builder machine, aluminum

radiator plastic tank clinching machine, aluminum radiator brazing furnace, aluminum radiator leak testing machine,

radiator header plate mold, radiator side plate mold, plastic tank die, etc.


Decoiler for side plate radiator making machine:
