Roller Continuous Mesh Belt Furnace For Screw Treatment Max 1500 Kg per Hour

Categories Mesh Belt Furnace
Place of Origin: Jiangsu, China (Mainland)
Brand Name: WONDERY
Model Number: RCW
Certification: CE
Supply Ability: 10 Set/Sets per Quarter
Packaging Details: Nude package for big parts, steel case or plywood case package for spare parts and accessories, PE weaving film for control cabinet
MOQ: 1 Set
Price: Negotiable
Payment Terms: L/C, T/T
Delivery Time: 90 Days
Name: Mesh Belt Furnace
Voltage: 380V
energy: electricity
production capacity: 160-1500 kg/h
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Roller Continuous Mesh Belt Furnace For Screw Treatment Max 1500 Kg per Hour

Roller Continuous Mesh Belt Furnace For Screw Treatment Max 1500 Kg per Hour

Main Features

1) To meet the production needs of fastening parts, the mesh belt furnace employs Taiwan technology, and improves its energy-saving

effect in the area of refractory lining.
2) The mesh belt furnace employs low-voltage heating through the transformer to prolong the service life of the heating tubes.
3) The mesh belt is supported by the support rollers with synchronized movement so that the mesh belt bears a minimum tension.
4) The rollers are supported by special high-pressure sealed bearing.
5) The mesh belt is designed with abnormal transportation alarm device to assure the stable movement of the mesh belt.
6) The drip-in atmosphere is gasified by a gasifier and then sent into the furnace. The atmosphere is monitored and controlled

continuously by an oxygen probe.
7) The hot mesh belt returns back to the entrance of the furnace and preheats the cold partss, which saves energy greatly.

Product Application

The mesh belt furnace is widely used for heat treatment of mechanical parts like automobile fittings, fastening,
chains, bearings and mechanical parts for tools etc. The furnace has the functions of automatic charging,
carburizing (or carburizing & nitriding), quenching, cleaning, cooling and tempering.
The computerizing office management is available through a computer control system equipped.

TECHNICAL PARAMETERS of mesh belt furnace
Working Temperature
Precleaning machine
40-60
Quenching furnace
820-950
Quenching tank
60-80
Working Temperature
Post-cleaning machine
40-60
Tempering furnace
200-450
Furnace Atmosphere
Quenching furnace
propane, methonal, ammonia
Tempering furnace
air

Model Table of mesh belt furnace


Model


Rated Power (Kw)


Rated temperature (degree celcius)


Dimensions of working zone (mm)
(mm)

Productivity (kg/h)
RCW-1110920400*4000*100160~200
RCW-2150920500*5500*100180~250
RCW-3180920600*6000*100300~350
RCW-4230920800*6000*100450~520
RCW-4A230920600*8000*100450~520
RCW-5300920800*8000*100550~720
RCW-6400920800*10000*100880~1000
RCW-75009201000*10000*1001000~1250
RCW-86009201000*12000*1001250~1500
