| Categories | Automatic Bagging Machine |
|---|---|
| Brand Name: | SANHE |
| Model Number: | DCS-25FWG |
| Certification: | ISO9001:2015, CE |
| Place of Origin: | Suzhou |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 90 Sets Per Month |
| Delivery Time: | 90 days |
| Packaging Details: | Wood Pallet |
| Product Name: | Bagging Machine |
| Function: | Filling Weighing ( can remove the air during filling ) |
| Packing Speed: | 30-100 bags per hour |
| Accuracy: | Generally (+/- ) 0.2% |
| Powder: | Electric |
| Origin: | Suzhou |
DCS-25FWG 25 Kg Bag Filling Scale with Suction Air Function Remove the Air During Filling
A. What is the 25 kg packing machine ?
It is used to transport materials (normally powder or granule ) from the silo to the packaging container, and it also has the function of weighing,
B. Discription of 25 Kg packing machine ?
Electronic quantitative packaging scale is a combination of electronic scale and automatic control. It weighs when feeding until it is close to the preset packaging value. The computer quantitative packing scale is composed of several independent weighing units with the structure of feeding and discharging. The computer quantitative packing scale is suitable for the quantitative packing of 25kg-50kg, and the electronic quantitative packing scale is widely used.
C. Application of 25Kg packing machine:
Powder quantitative packaging machine is suitable for the quantitative packaging of powder, powder and powder materials in chemical, food, agricultural and sideline products industries, such as milk powder, starch, pesticide, veterinary medicine, premix, additive, condiment, feed, enzyme preparation, etc.; powder quantitative packaging machine is a combination of machine and instrument, controlled by single chip microcomputer, with automatic quantitative, automatic filling and automatic adjustment of measurement error Etc.
D. According to the different styles of packaging bags, it can be divided into open mouth bag packing machine and valve type bag packing machine
The parameter and function table :
| Scope of Application DCS-25FWG | |
| Suitable materials | 1. Ultrafine Powder 2. Powder material contains much air 3. Material density is very small and needs to be compacted |
| Suitable packing container | Open mouth bag |
| Feeding type | Screw feeder |
| Alternative feeding type | Air feeder |
| Technical parameters | |
| Weighing range(Kg) | 25 |
| Packing speed(bag/H) | 30-100 |
| Packing Accuracy | Generally (+/- ) 0.2% ( Note: special materials shall depend on the industrial standard ) |
Features & advantages
1. Load cell and digital weighing controller, high accuracy;
2. High automation level, automaticly feeding, weighing, sucting, easy to use;
3. Suct the air from the material ,compact the material;
4. No dust escape pollution when packing.
FAQ
Please Send us The Details We Required :
1. Name of material to be filled in bag ?
2. Weight capacity of each bag ?
3. How many bags fill per hour ?
4. Your materials characte ?
Our core products
Automatic open mouth bag packing and palletizing line
Automatic valve bag packing and palletizing line
Automatic packing and palletizing line
Open mouth bag packing machine for granular
Open mouth bag packing machine for powder
Valve bag packing machine for granular
Valve bag packing machine for powder
Big bag packing machine
Big bag unloading station
Liquid filling machine
Various conveyors
Open Mouth Bag Suction Packer
The parameter and function table of the Open Mouth Bag Exhaust Packer
DCS-25(P01G-S) | DCS-25(PO3G-S) (negative pressure Exhausting) | |
Scope of application | ||
Suitable materials | Powder and thin granule of good Air affinity | Powder and thin granule of good Air affinity |
Suitable packing container | Open mouth bag | Open mouth bag |
Feeding type | Above and below the two screws | Air flow type |
Alternative feeding type | × | Screw type |
Technical parameters | ||
| Weighing range (Kg) | 5-50 | 5-50 |
Packing speed(bag/H) | 30-100 | 30-100 |
| Packing Accuracy | Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard) | |
Control function | ||
Automatic tare | ○ | ○ |
Automatic quick and slow feeding | ○ | ○ |
Automatic free fall compensation | ○ | ○ |
Automatic minus deviation | ▲ | ▲ |
Automatic over weight alarms | ○ | ○ |
Automatic self diagnosis failure | ○ | ○ |
Manual/Automatic mode conversation | ○ | ○ |
Communication port | ▲ | ▲ |
Manual adjusting the height of bag | ○ | ○ |
Important auxiliary function | ||
| × | ○ | |
negative pressure Exhausting function | ○ | × |
Arch break function of hopper | ▲ | ▲ |
Vibration at the bottom of the bag | ▲ | ▲ |
Powder protection | ||
Inflatable seal | ▲ | ▲ |
Negative pressure dusting(not contain duster) | ▲ | ▲ |
Valve for leak-proof | × | ○ |
Safety protection | ||
Electrostatic grounding | ▲ | ▲ |
| ▲ | ▲ | |
Stop packing when lose power | ○ | ○ |
Emergency stop | ○ | ○ |
Ex-proof | ▲ | ▲ |
Mark: “○”is standard function；“▲”is choose function ；“×”is not has function | ||
Main specialty
*Suit for material contain many air which use open mouth bag to packing.
*Can exhausting the air in material, improve the bulk density of material in bag. It not wasting material.
*Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.
|
