316Ti / UNS precision ground tubing ASTM TYPE S31635 Custom Cutting

316Ti / UNS precision ground tubing ASTM TYPE S31635 Custom Cutting

Available Tube Product Forms:

Straight.
Coiled.
Welded and Cold Redrawn.

Quality Assurance:

Spezilla's 1.4571 / TP316Ti welded precision stainless steel tubes are produced acc. to the following process and inspection to assure our quality:

1. Chemical Composition Analysis Test With 100% PMI.

2. Solution Annealing / Bright Annealed.

3. 100% Hydrostatic Test and 100% Eddy Current Test

4. Mechanical Tests includes Tension Test, Flattening Test, Flaring Test, Hardness Test.

5. Impact Test subject to Standard request.

6. Grain Size Test and Intergranular Corrosion Test.

7. Visual Test and Endoscope Test for Surface Quality Test

Typical Applications:

Flue gas applications

Heat Exchangers

Heating Elements


Typical Manufacturing Specifications:

EN10217-7

ASTM A249

ASTM A269

Also individual customer specifications.

Description:

316Ti/4571 Welded precision stainless steel tubing is a titanium-stabilized, molybdenum-alloyed austenitic alternative to 316L/4404 – mainly used for elevated temperature applications. Due to its titanium-stabilization this product is weldable in all thickness ranges without becoming susceptible to intergranular corrosion. It belongs to the standard CrNiMo stainless steel family.

Due to their molybdenum content, the austenitic CrNiMo standard grades can be used in applications with increased demand for corrosion resistance. Their well-balanced material properties make them suitable for the fabrication of many products. Due to its titanium content, 316Ti/4571 can also be used at elevated temperatures.

316Ti/4571 is commonly available from many stainless steel stockists in many product forms and dimensions. Due to its titanium alloying, polishing options for 316Ti/4571 are limited.

Description:

1.4571 Stainless Steel / Spec: EN10217-7 / EN10088

Spezilla specialise in manufacturing high quality precision stainless steel tube and other corrosion resistant alloy tubes that are designed to industry and customer specifications. Our products are manufactured to the highest quality standards and are very competitively priced. Our mission is to provide customized, flawless, reliable, and affordable corrosion resistant steel tubes to the world.

Tube Type:            Welded, Welded & Drawn. Straight Length or Coils.

Tube Materials:      Austenitic:    304, 304L, 316L, 321, 316Ti, 317L, 904L, 254 SMO;

                                                   1.4301, 1.4307, 1.4401, 1.4404, 1.4541, 1.4571, 1.4539, 1.4547;

                              Duplex:         2205, 2507;  1.4462, 1.4410;

                              Ferritic:         409, 439, 441, 444; 1.4512, 1.4510, 1.4509, 1.4521;

                              Nickel Alloy:  800, 800H, 800HT, 825, C276; 1.4876, 1.4958, 1.4959, 2.4858, 2.4819;

                              Titanium:       Gr.1, Gr.2;

Tube Size:              O.D. 4.00 - 38.10MM, W.T. 0.30 - 3.0MM.

Tube Finish:           As Welded, Bright Annealed, Annealed & Pickled, Polished, Custom Cutting.

Tube Standards:    ASTM A249, A268, A269, A270, A688, A789, B338;

                               EN 10217-7 TC1 & TC2, EN 10296-2, EN10357 etc.

Applications:          Heat Exchangers, Food & Beverage, Heating Elements, Automative, Tube Manipulation etc.

Spezilla appreciates the opportunity to help you with your questions about our operations, our products, our services or any other aspect of our business. We understand the demands of placing orders and the need for fast quotes, so we guarantee a response in 24 hours or less.
